FUJITSU Storage

ETERNUS DX S5 series

Hybrid Storage Systems

Operation Guide (Basic)

Operation management/maintenance

P3AG-3992-02ENZ0

Table of Contents

Other manuals for Fujitsu ETERNUS DX60 S5

Design Guide335 pages

Configuration Guide75 pages

Questions and Answers:

K
Krystal KrauseAug 5, 2025
Why is my Fujitsu ETERNUS DX60 S5 Storage ETERNUS DX not connecting via network service?
- N
  njohnsonAug 5, 2025
  If your Fujitsu Storage ETERNUS DX cannot be connected via a network service, consider the following: * Ensure the ETERNUS DX is powered on. * Verify the LAN cable is properly connected. * Check for any failed network devices, such as a LAN switch or router. * Confirm that the network service environment settings are valid. * Ensure the IP address is correct. * Verify the settings for the ETERNUS DX LAN ports (firewall) are valid.
M
mackenziestewartAug 9, 2025
What to do if my Fujitsu ETERNUS DX60 S5 Storage ETERNUS DX refuses to turn on?
- T
  Tracy BarnesAug 9, 2025
  If your Fujitsu Storage ETERNUS DX refuses to turn on, please check the following: * Ensure the power cord is connected properly. * Verify the PSU switch of the power supply unit is turned to the ON position. * Confirm the main line switch of the power distribution unit is not turned OFF. * Check for any power failures. * Ensure the mini SAS HD cable between enclosures is connected.
M
Mrs. Joanna JohnsonAug 14, 2025
Why is I/O access slow on my Fujitsu ETERNUS DX60 S5 Storage?
- W
  william07Aug 14, 2025
  If you are experiencing slow I/O access on your Fujitsu Storage, consider the following checks: 1. Ensure the ambient temperature is within operating environment conditions. 2. Check the battery status using ETERNUS Web GUI. 3. Use ETERNUS Web GUI to check for abnormalities in each component on the [Storage] screen of [Component]. 4. Check the path status. 5. If using ETERNUS Multipath Driver, start ETERNUS Multipath Manager. 6. Check the loading of the ETERNUS DX. 7. Check the transfer rate of the FC port. 8. Check the number of command queues in the server. 9. Check the message log of the OS on the connected server. 10. Check the status of the RAID group. 11. Check the cache parameter settings of the volumes.
L
Lauren TuckerAug 18, 2025
What to do if FAULT LED Is On on Fujitsu ETERNUS DX60 S5 Storage?
- A
  Amber Roberts DDSAug 18, 2025
  If the FAULT LED is illuminated on your Fujitsu Storage, try the following: * Check the general status and system messages in the ETERNUS Web GUI. * Verify that the mini SAS HD cable between enclosures is properly connected on both sides. * Check the connection of the mini SAS HD cable between enclosures. * Ensure that the l (IN) and n (OUT) sides of the mini SAS HD cable between enclosures are connected correctly.
P
perezkennethAug 22, 2025
What to do if server does not recognize volumes on Fujitsu ETERNUS DX60 S5?
- A
  Amy WilsonAug 22, 2025
  If the server does not recognize the volumes on your Fujitsu Storage, you should: * Check the status of the ETERNUS DX and other devices, including network devices, connecting the server and the ETERNUS DX. * Check for errors in the path using a path management tool like ETERNUS Multipath Manager.
N
nathan23Aug 27, 2025
How to reconnect mini SAS HD cable on Fujitsu Storage?
- C
  Carlos RodriguezAug 27, 2025
  When a mini SAS HD cable between enclosures is not connected: * Press the controller enclosure's Power switch for four seconds or more to turn off the ETERNUS DX. * Connect the mini SAS HD cable between enclosures while the drive enclosure is on. * Press the controller enclosure's Power switch to turn on the ETERNUS DX.
H
Henry JacobsAug 31, 2025
What to do if mini SAS HD cable is incorrectly connected on Fujitsu ETERNUS DX60 S5 Storage?
- J
  jameskochAug 31, 2025
  When the l (IN) and n (OUT) sides of the mini SAS HD cable between enclosures are incorrectly connected or the cable is connected in the wrong order: * Press the controller enclosure's Power switch for four seconds or more to turn off the ETERNUS DX, and turn off the AC power. * Reconnect the mini SAS HD cable between enclosures. * Make sure that AC power is being supplied, then turn the ETERNUS DX on.

Fujitsu ETERNUS DX60 S5 Specifications

General

Brand	Fujitsu
Model	ETERNUS DX60 S5
Category	Storage
Language	English

Summary

Basic Operation Guide

Powering On and Off ETERNUS DX

Steps for turning the ETERNUS DX system on and off.

Using FUNCTION Button and Setting Change Switches

Storage System Monitoring

Displaying Status via ETERNUS Web GUI

Monitoring system status through the Web GUI interface.

Displaying Status via ETERNUS CLI

Component Expansion and Function Enhancement

License Registration

Installing Additional Drives

Steps for installing new drives into the ETERNUS DX system.

Installing Additional Drive Enclosures

Guide for adding extra drive enclosures to expand storage capacity.

Installing Long Wave SFP+ Modules (16Gbit/s)

Procedure for replacing SFP+ modules with long wave variants.

Adding Servers

Troubleshooting Guide

Troubleshooting Check List

A guide to diagnose and resolve common operational issues.

Required Information for Inquiries

Details needed when contacting support for troubleshooting.
