Pad ASSY
NOTE
The life span of the Pad ASSY is about 100,000 sheets or one year. Use the Abrasion counter on the
Operator panel to estimate when the Pad ASSY needs replacement. The life span may be decreased by
as much as half when carbonless paper is read frequently.
WARNING
Turn off the power before replacing the Pad ASSY.
Pull the ADF lever to open the ADF.
Push the Pick Arm carefully.
ADF lever
Pad ASSY
Pick Arm
To Next Page
