Fujitsu FO14R Series User Manual

5
GENERAL INFORMATION
General Information
Electrical and Physical Data
(RLA) (LRA)
Minimum
Amperes
Maximum
Amperes
[L/s]
[kg]
18 C 208-230 1 60 9/9 48.0 0.75 12/12 15/15 20/20 11.14 [1.03] 1 2478 [1169] 123 [3487] 152 [68.9] 159 [72.1]
18 F 208-230 1 60 9/9 48.0 0.75 12/12 15/15 20/20 11.14 [1.03] 1 2478 [1169] 123 [3487] 152 [68.9] 159 [72.1]
24 A 208-230 1 60 10.3/10.3 61.6 0.7 14 20/20 20/20 9.06 [0.84] 1 2411 [1137] 89 [2523] 146 [66.2] 153 [69.4]
24 F 208-230 1 60 10.9/10.9 62.9 0.7 15 20/20 25/25 11.14 [1.03] 1 2478 [169] 105 [2977] 152 [68.9] 159 [72.1]
30 A 208-230 1 60 14.1/14.1 73 0.7 19 25/25 30/30 11.14 [1.03] 1 2535 [1196] 106 [3005] 155 [70.3] 162 [73.5]
30 F 208-230 1 60 12.8/12.8 67.8 1 18 25/25 25/25 17.29 [1.61] 1 3852 [1817] 116 [3288] 191 [86.6] 198 [89.8]
36 A 208-230 1 60 16.7/16.7 79 0.6 22 30/30 35/35 14.82 [1.38] 1 3333 [1573] 111 [3146] 177 [80.3] 184 [83.5]
36 F 208-230 1 60 15.4/15.4 83.9 2.8 22 30/30 35/35 19.76 [1.84] 1 3121 [1472] 118 [3345] 199 [90.3] 206 [93.4]
42 A 208-230 1 60 17.9/17.9 112 0.9 24 30/30 40/40 14.82 [1.38] 1 2933 [1384] 155 [4394] 201 [91.2] 208 [94.3]
42 F 208-230 1 60 17.9/17.9 112 1 24 30/30 40/40 19.76 [1.84] 1 3815 [1800] 139 [3941] 221 [100.2] 228 [103.4]
48 A 208-230 1 60 21.8/21.8 117 1.2 29 35/35 50/50 19.76 [1.82] 1 4055 [1913] 143 [4054] 227 [103.0] 234 [106.1]
48 F 208-230 1 60 18.5/18.5 124 2.8 26 35/35 40/40 24.23 [2.25] 1 4379 [2066] 188 [5330] 257 [116.6] 264 [119.7]
60 B 208-230 1 60 23.7/23.7 152.5 1.00 31/31 40/40 50/50 28.26 [2.63] 1 3654 [1724] 212 [6010] 278 [126.1] 285 [129.3]
60 F 208-230 1 60 23.7/23.7 152.5 1 31 40/40 50/50 28.26 [2.62] 1 3654 [1724] 212 [6010] 278 [126.1] 285 [129.3]
36 A 208-230 3 60 10.4 73 0.6 14 20/20 20/20 14.82 [1.38] 1 3333 [1573] 111 [3146] 177 [80.3] 184 [83.5]
36 F 208-230 3 60 10.4 73 2.8 16 20/20 25/25 19.76 [1.84] 1 3121 [1472] 124 [3515] 199 [90.3] 206 [93.4]
42 A 208-230 3 60 13.5 88 1 18 25/25 30/30 14.82 [1.38] 1 2933 [1384] 155 [4394] 201 [91.2] 208 [94.3]
42 F 208-230 3 60 13.5 88 1 18 25/25 30/30 19.76 [1.84] 1 3815 [1800] 145 [4110] 221 [100.2] 228 [103.4]
48 A 208-230 3 60 13.7 83.1 1.2 19 25/25 30/30 19.76 [1.84] 1 4055 [1913] 143 [4054] 227 [103.0] 234 [106.1]
48 F 208-230 3 60 13.8 83.1 2.8 21 25/25 30/30 24.23 [2.25] 1 4379 [2066] 194 [5500] 257 [116.6] 264 [119.7]
60 B 208-230 3 60 15.9/15.9 110.0 1 21/21 25/25 35/35 28.26 [2.63] 1 3654 [1724] 212 [6010] 278 [126.1] 285 [129.3]
60
F 208-230 3 60 15.9 110 1
21 25/25 35/35 28.26 [2.62] 1 3654 [1724] 223 [6321] 278 [126.1] 285 [129.3]
36 A 460 3 60 5.8 38 0.5 8 15/15 15/15 14.82 [1.38] 1 3333 [1573] 111 [3146] 177 [80.3] 184 [83.5]
42 A 460 3 60 6 44 0.5 8 15/15 15/15 14.82 [1.38] 1 2933 [1384] 155 [4394] 201 [91.2] 208 [94.3]
48 A 460 3 60 6.2 41 0.6 9 15/15 15/15 19.76 [1.84] 1 4055 [1913] 143 [4054] 227 [103.0] 234 [106.1]
60 A 460 3 60 7.1 52 0.5 10 15/15 15/15 24.23 [2.25] 1 4780 [2255] 232 [6577] 262 [118.8] 269 [122.0]
Model #
Capacity
Major
Series
Refrig. Per Circuit
(oz.) [g]
Weight
Face Area Sq. Ft.
[m
2
]
No. Rows Shipping Lbs. [kg]
ELECTRICAL PHYSICAL
Voltage Phase Freq
Compressor
Fan Motor Full
Load Amperes (FLA)
Minimum Circuit
Ampacity Amperes
Outdoor Coil
Rated Load
Amperes
Locked Rotor
Amperes
Fuse or HACR
Circuit Breaker
CFM
Net
Lbs.
(RLA) (LRA)
Minimum
Amperes
Maximum
Amperes
[L/s] [kg]
18 A
208-230 1 60
9/9
48 0.6 14 20/20 20/20 14.82 [1.38] 1 2478 [1169] 100 [2835] 171 [77.6] 178 [80.7]
24 A
208-230 1 60 10.9/10.9 62.9 0.6 16 20/20 25/25 14.82 [1.38] 1 2478 [1169] 108 [3062] 171 [77.6] 178 [80.7]
30 A
208-230 1 60 12.8/12.8 67.8 1 19 25/25 30/30 17.29 [1.61] 1 3852 [1817] 118 [3345] 160 [72.6] 167 [75.7]
36 A
208-230 1 60 15.4/15.4 83.9 3.5 25 30/30 40/40 22.23 [2.07] 1 3121 [1473] 141.6 [4014] 180 [81.6] 187 [84.8]
42 A
208-230 1 60 16.7/16.7 109 1 25 30/30 40/40 19.76 [1.84] 1 3815 [1800] 148 [4196] 220 [99.8] 228 [103.4]
48 A
208-230 1 60 18.5/18.5 124 2.8 29 35/35 45/45 28.26 [2.62] 1 4374 [2067] 191.2 [5420] 236 [107.0] 243 [110.2]
Model #
Capacity
Face Area Sq. Ft.
[m
2
] No. Rows Shipping Lbs. [kg]
Major
Series
Refrig. Per Circuit
(oz.) [g]
Weight
ELECTRICAL PHYSICAL
Voltage Phase Freq
Compressor
Fan Motor Full
Load Amperes (FLA)
Minimum Circuit
Ampacity Amperes
Outdoor Coil
14 SEER Single Stage Heat Pump - with Piston
Rated Load
Amperes
Locked Rotor
Amperes
Circuit Breaker
Fuse or HACR
CFM
Net
Lbs.
(RLA) (LRA)
Minimum
Amperes
Maximum
Amperes
[L/s] [kg]
18 C
208-230 1 60 9/9 48.0 0.75 12/12 15/15 20/20
11.14 [1.03]
1
2478 [1169] 123 [3487]
152 [68.9] 159 [72.1]
24 A
208-230 1 60 10.3/10.3 61.6 0.7 14 20/20 20/20 11.14 [1.03] 1 2478 [1169] 88 [2495] 152 [68.9] 159 [72.1]
24 B
208-230 1 60 10.9/10.9 62.9 0.7 15 20/20 25/25 11.14 [1.03] 1 2478 [1169] 105 [2977] 152 [68.9] 159 [72.1]
30 A
208-230 1 60 14.1/14.1 73 1 19 25/25 30/30 17.29 [1.61] 1 3852 [1817] 122 [3459] 191 [86.6] 198 [89.8]
30 B
208-230 1 60 12.8/12.8 67.8 1 18 25/25 25/25 17.29 [1.61] 1 3852 [1817] 116 [3288] 191 [86.6] 198 [89.8]
36 A
208-230 1 60 15.4/15.4 83.9 2.8 22 30/30 35/35 19.76 [1.84] 1 3121 [1472] 118 ]3345] 199 [90.3] 206 [93.4]
42 A
208-230 1 60 17.9/17.9 112 1 24 30/30 40/40 19.76 [1.84] 1 3815 [1800] 139 [3941] 221 [100.2] 228 [103.4]
48 A
208-230 1 60 18.5/18.5 124 2.8 26 35/35 40/40 24.23 [2.25] 1 4379 [2066] 188 [5330] 257 [116.6] 264 [119.7]
60 A
208-230 1 60 23.7/23.7 152.5 1 31 40/40 50/50 28.26 [2.62] 1 3654 [1724] 212 [6010] 278 [126.1] 285 [129.3]
36 A
208-230 3 60 10.4 73 2.8 16 20/20 25/25 19.76 [1.84] 1 3121 [1472] 124 [3515] 199 [90.3] 206 [93.4]
42 A
208-230 3 60 13.5 88 1 18 25/25 30/30 19.76 [1.84] 1 3815 [1800] 145 [4110] 221 [100.2] 228 [103.4]
48 A
208-230 3 60 13.8 83.1 2.8 21 25/25 30/30 24.23 [2.25] 1 4379 [2066] 194 [5500] 257 [116.6] 264 [119.7]
60 A
208-230 3 60 15.9 110 1 21 25/25 35/35 28.26 [2.62] 1 3654 [1724] 223 [6321] 278 [126.1] 285 [129.3]
Model #
Capacity
Major
Series
ELECTRICAL PHYSICAL
Voltage Phase Freq
Compressor
Fan Motor Full
Load Amperes (FLA)
Minimum Circuit
Ampacity Amperes
Outdoor Coil
Refrig. Per Circuit
(oz.) [g]
Weight
Face Area Sq. Ft.
[m
2
] No. Rows Shipping Lbs. [kg]
Rated Load
Amperes
Locked Rotor
Amperes
Fuse or HACR
Circuit Breaker
CFM
Net
Lbs.
