Caution: As the connector is clipped in place after insertion in order to
prevent it from falling off, when performing insertion, (1) grip
the cable base with one hand, (2) slide the outer part of the
connector upwards with the other hand (3) and push in until
it locks into place.
(3)Connect the plug of the power cable to electrical outlet.
(4) Plug the other end of the power cord into the power outlet.
Outer section of
the connector
Base of the cable
3
2
1
