System expansions
Opening the casing
Casing,De vice,
► Switch the device off. The device must not be in power-saving mode.
Please observe the safety information in "Important notes", Page 11.
Disconnect the mains plug from the mains outlet.
Only insert the power plug after you have closed the casing.
Open the casing carefully because there are WLAN cables that lead from the casing
cover to the system and the se may break if the casing is opened carelessly.
► Remove a ny connected wi
res which are in the way.
2
2
3
1
1
► Loosen the screws at the rear (1).
► Slide the casing cover in the direction of the arrow (2) and swing out the
casing cover towards the front (3).
34 Fujitsu
