Fujitsu FUTRO S920 User Manual

Getting started
Connecting a monitor
Only attach the screen to y our device when it is switched off.
► Follow the instructions contained in the m onitor manual to prepare the monitor
for operation (e.g. connecting cables).
Monitor,
► Connect the data c able to the required monitor port on your device.
► Plug the monitor power cable into the grounded mains outlet.
Connecting the mouse
You can connect a USB mouse or a PS/2 mouse to your device .
Mouse,Connecting,
Connecting a USB mouse
► Connect the USB mouse to one of the USB ports on the device.
USBport,USB p ort
Connecting a PS/2 mouse
The PS/2 mouse is only detected by the device if you connect the mouse w h en
the device is s witched off and then switch the device o n again.
► Connect th e PS/2 mouse to the PS/2 mouse port of the device.
PS/2mouse,Connect ing,PS/2mouse,
► Switch your device on again.
Connecting the keyboard
You can connect a USB keyboa rd or a PS/2 keyboard to your device.
Keyboard,Connecting,
Connecting a USB keyboard
Use the supplied keyboard cable only.
USBport,Conne cting,
► Insert the flat rectangular USB plug of the keyboard cable into one of the device’s USB ports.
USBport
Connecting a PS/2 keyboard
Use the supplied keyboard cable only.
ConnectingaP S /2keyboardConnecting,
The P S/2 keyboard is only detected b y the d evice if you connect the keyboa rd
when the device is switched off and then switch the device on again.
► Switch your device off.
► Plug the round plug of the keyboard cable into the keyboard port on the device.
Key
board,
► Switch your device on again.
22 Fujitsu

Fujitsu FUTRO S920 Specifications

General

L2 cache	2 MB
Processor cores	4
Processor model	GX-415GA
Processor family	AMD G
Processor frequency	1.5 GHz
Storage media	Flash
Card reader integrated	No
Total storage capacity	8 GB
Memory slots	1x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Memory layout (slots x size)	1 x 4 GB
On-board graphics card model	AMD Radeon HD 8330E
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Operating system installed	Windows Embedded Standard 7
Product color	Black
Operating temperature (T-T)	10 - 35 °C
Sustainability certificates	EPEAT Gold, ENERGY STAR
AC input voltage	120-230 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	195 mm
Width	52 mm
Height	250 mm
Weight	1300 g
