Getting to Know Your LIFEBOOK
(This picture is for illustration purpose only and may look di󰀨erent from the actual unit)
Side view of LIFEBOOK
■■
Right view
1
Audio In/Out Jack
USB 3.2 (Gen 1) Connector
The USB 3.2 (Gen 1) connector allows you
to connect Universal Serial Bus devices and
backward compatible with USB 2.0 devices.
DisplayPort
HDMI Connector
1.
2.
3.
4.
2
5E15A1
3
4
5 6
LAN Connector
It allows you to connect to a LAN (local area
network) using an optional LAN cable.
Kensington Lock Slot
It allows you to attach an optional physical
lock to lock down the device.
5.
6.
