Removing and installing com ponents
during servicing
Removing and installing the har
ddisk
Removing a cover
► Remove the battery (see Chapter "Removing a battery " , Page 33).
1
1
2
► Remove the screws (1).
Keep the screws in a safe place. If you are removing more than one componen t at
the same time, store the screws for the individual components separately from each
other. If you install the wrong screws, components may b e da maged.
► Lift the c over
off the noteb ook (2).
Removing a hard disk
1
2
► Use the pulling aid to pull the hard disk in the direction of the arrow (1) until the contacts disengage.
► Remove the hard disk from the hard disk compartment (2).
72 Fujitsu Technology Solutions
