22 Operating Manual CX2550/60/70 M4
Functional overview
RAID controllers (expansion cards)
Slots
Drives
SATA Controller Intel
®
C624, for up to 6 x SATA HDDs/SSDs
SW Raid 0/1
RAID controllers – RAID Controller, SAS/SATA 12 Gbit/s, Fujitsu
PRAID CP400i, 8 ports int. RAID level: 0, 1, 1E,
10, 5, no FBU support
– RAID 5/6 Controller, SAS/SATA 12 Gbit/s, Fujitsu
PRAID EP580i, 16 ports int. RAID level: 0, 1, 10,
5, 50, 6, 60, 8 GB, FBU support
– RAID 5/6 Controller, SAS/SATA 12 Gbit/s, Fujitsu
PRAID EP540i, 16 ports int. RAID level: 0, 1, 10,
5, 50, 6, 60, 4 GB, FBU support
– RAID 5/6 Controller, SAS/SATA 12 Gbit/s, Fujitsu
PRAID EP520i, 16 ports int. RAID level: 0, 1, 10,
5, 50, 6, 60, 2 GB, FBU support
– RAID 5/6 Controller, SAS/SATA 12 Gbit/s, Fujitsu
PRAID EP420i, 8 ports int. RAID level: 0, 1, 10,
5, 50, 6, 60, 2 GB, FBU support
– RAID 5/6 Controller, SAS/SATA 12 Gbit/s, Fujitsu
PRAID EP400i, 8 ports int. RAID level: 0, 1, 10,
5, 50, 6, 60, 1 GB, FBU support
– PSAS CP400i, 8-port, 12Gb/s SAS+SATA PCIe
Host Bus Adapter
PCI-Express 3.0 x 16 2 x for low profile via riser card
OCP card 1x PCI-Express Mezz x 16 or 1x PHY Mezz
HDDs 6 x 2.5-inch
