2.2 Server node specification
This section explains the specifications for the server node. The specifications
for the server nodes are liable to be updated without any notice. Please be
forewarned.
2.2.1 CX2550 M4
System board
Processor (CPU)
Memory modules configuration
Interfaces
System board type D3853
Chipset Intel
®
C621
CPU quantity and type 2 x Intel
®
Xeon
®
Processor Scalable Family
Memory slots 16
Memory slot type DDR4
Memory capacity
(min. - max.)
8 GB - 2048 GB
Memory protection Advanced ECC; SDDC (Chipkill™)
Memory notes Supports R-DIMM, LR-DIMM
Y-cable connector 2 x USB 3.0, 1x VGA
LAN / Ethernet (RJ-45) 1 x Gbit/s Ethernet (Shared LAN)
Management LAN
(RJ45)
1 x Gbit/s Ethernet.
Management LAN traffic can be switched to shared
LAN port.
