CX2550/60/70 M4 Operating Manual 55
6 Starting up and operation
V CAUTION!
Please note the safety instructions in chapter "Important information" on
page 33.
I Controls and indicators are the same for the CX2550 M4 / CX2560 M4 /
CX2570 M4.
6.1 Controls and indicators
6.1.1 Controls and indicators on the server node
Figure 6: Controls and indicators of the server node CX2550 M4
Pos. Label Indicator Status Description
1
Power-on
indicator
off The server node is switched off.
green on
–
The server node is in power-on
delay and the system is in
normal operation (S0).
green
flashing
slowly
(1/2 Hz)
The iRMC S5 is initialized and is
getting ready.
