2 ID
ID indicator,
see also
"iRMC-
related
status
signals" on
page 57
blue on
The system has been selected by
pressing on the ID button in the
chassis front panel.
blue
flashing
The server has been highlighted for
easy identification using the iRMC
(AVR) with disabled local VGA
output.
3 [CSS]
CSS
indicator
off
No critical event detected (CSS
component).
orange on
Prefailure event detected (CSS
component).
orange
flashing
CSS component failure detected.
4
Global Error
indicator,
see also
"iRMC-
related
status
signals" on
page 57
off
No critical event detected (non CSS
component).
orange on
Prefailure event detected (non CSS
component).
orange
flashing
Non CSS component failure
detected.
Possible causes:
– System is out of the specified
temperature range
– Defective sensor
– CPU error
– Error detected by server
management software
Pos. Label Button Function
1 On/Off button
Used to switch the server on or off.
I If the system is running an ACPI-
compliant operating system, pressing
the On/Off button will perform a graceful
shutdown.
Pos. Label Indicator Status Description
