I The server nodes are controlled via related operating panel areas on the
front side of the CX400 M4 server enclosure. See "FUJITSU Server
PRIMERGY CX400 M4 Server Enclosure Operating Manual".
iRMC-related status signals
I For further information, please refer to chapter "Updating or recovering
the iRMC" in the Upgrade and Maintenance Manual.
5 RESET Reset button
Reboots the system.
Press the reset button with a straightened end
of a paper clip.
V CAUTION!
Risk of data loss!
ID indicator
Global error
indicator
Description
blue flashing off
A remote connection has been
established. Local VGA output has
been disabled during the remote
session.
blue flashing orange flashing
An emergency flash of the iRMC
firmware is in progress.
Pos. Label Button Function
