5.2 Connecting devices to the server node
The additional connectors available on your server node depend on the
expansion cards installed. For further information refer to the “FUJITSU Server
PRIMERGY CX2550 M4 / CX2560 M4 / CX2570 M4 Server Node Upgrade and
Maintenance Manual”.
The standard connectors are marked with symbols, and some are color-coded:
Figure 2: Rear connectors on the server node CX2550 M4 (Air cooling) / CX2560 M4
Figure 3: Rear connectors on the server node CX2550 M4 (Liquid cooling) / CX2560 M4
1 Management LAN connector 3 Y-cable connectors (2x USB, 1x
VGA)
2 Shared LAN connector
