26 Operating Manual CX2550/60/70 M4
Functional overview
2.2.3 CX2570 M4
System board
Processor (CPU)
Memory modules configuration
Interfaces
Onboard or integrated controllers
System board type D3854
Chipset Intel
®
C624
CPU quantity and type 2 x Intel
®
Xeon
®
Processor Scalable Family
Memory slots 16
Memory slot type DDR4
Memory capacity
(min. - max.)
8 GB - 2048 GB
Memory protection Advanced ECC; SDDC (Chipkill™)
Memory notes Supports R-DIMM, LR-DIMM
Y-cable connector 2 x USB 3.0, 1x VGA
LAN / Ethernet (RJ-45) 1 x Gbit/s Ethernet (Shared LAN)
Management LAN
(RJ45)
1 x Gbit/s Ethernet.
Management LAN traffic can be switched to shared
LAN port.
LAN controller Intel
®
Ethernet Controller I210, 1 x 10/100/1000
Mbit/s Ethernet (TCP/IP acceleration)
Remote Management
Controller
iRMC S5 (integrated Remote Management
Controller), IPMI 2.0 compatible
