Onboard or integrated controllers
RAID controllers (expansion cards)
Slots
Drives
LAN controller Intel
®
Ethernet Controller I210, 1 x 10/100/1000
Mbit/s Ethernet (TCP/IP acceleration)
Remote Management
Controller
iRMC S5 (integrated Remote Management
Controller), IPMI 2.0 compatible
SATA Controller Intel
®
C621, for up to 2x SATA HDDs/SSDs
SW Raid 0/1
RAID controllers – RAID Controller, SAS/SATA 12 Gbit/s, Fujitsu
PRAID CP400i, 8 ports int. RAID level: 0, 1, 1E,
10, 5, no FBU support
– RAID 5/6 Controller, SAS/SATA 12 Gbit/s, Fujitsu
PRAID EP420i, 8 ports int. RAID level: 0, 1, 10,
5, 50, 6, 60, 2 GB, FBU support
– RAID 5/6 Controller, SAS/SATA 12 Gbit/s, Fujitsu
PRAID EP400i, 8 ports int. RAID level: 0, 1, 10,
5, 50, 6, 60, 1 GB, FBU support
– PSAS CP400i, 8-port, 12Gb/s SAS+SATA PCIe
Host Bus Adapter
PCI-Express 3.0 x 16 2 x for low profile via riser card
OCP card 1x PCI-Express Mezz x 16
HDDs 2 x 2.5-inch
