68 Operating Manual RX2520 M4
Starting up and operation
6.1.1.3 Indicators on the accessible drives / components
Indicator on the ODD
Figure 15: Indicator on the ODD
I There are also ODDs without activity indicators.
6.1.1.4 Indicators on the HDD/SSD modules
Indicators on the hot-plug HDD/SSD module
Figure 16: Indicators on the hot-plug HDD/SSD module
Pos. Indicator Status Description
1
Activity
indicator
off The ODD is inactive.
green on The storage medium is being accessed.
