Functional overview
Drive bays
Operating Panel
Hard disk bay
configuration
6x 3.5-inch, for SAS / SATA or
4x 2.5-inch, 8x 2.5-inch, 12x 2.5-inch, 16x 2.5-inch
for SAS/SATA/SSD optional
Accessible drive bays 1 x 5.25-inch for LTO drive or
1 x 3.5-inch for DAT/RDX drive or
1 x 3.5-inch for ODD drive or
1 x 3.5/0.5-inch for ServerView Local Service
Display
Notes accessible drives all possible options described in relevant system
configurator
Operating buttons On/off button
Reset button
NMI button
ID button
Status LEDs Global error indicator (orange)
ID indicator (blue)
HDD/SSD activity indicator (green)
Power-on indicator (orange / yellow / green)
HDD/SSD error indicator (orange)
PSU error indicator (orange)
Temperature error indicator (orange)
CPU error indicator (orange)
Memory error indicator (orange)
Fan error indicator (orange)
ID indicator (blue)
CSS indicator (yellow)
