56 Operating Manual TX100 S3
Starting up and operation
– System already installed:
Ê Press the On/Off button (see item 1 in figure 5 on page 52).
The server is switched on, performs a system test and boots the
operating system.
– Starting the system with a 0-Watt device:
This 0-Watt device is equipped with a push button mains switch (1). This
switch is used to switch on a 0-Watt device when the lithium battery is
discharged.
Figure 7: 0-Watt device
Ê Press the push button mains switch one-time.
Ê Press the On/Off button on the front of the server.
Switching the server off
Ê Shut down the operating system properly.
The server is switched off automatically and goes into standby mode.
I If the operating system does not switch the server off automatically, press
the On/Off button for at least four seconds and/or send a corresponding
control signal.
/
