60 Operating Manual TX140 S2
Starting up and operation
The drive cover is replaced and the server locked in the reverse order.
Figure 6: Removing the drive cover from the HDD cover
Ê Carefully pull out on the green release lever (1) and lift off the drive cover (2).
