Installing the NAS
Fujitsu 15
When the configuration is finished, the NAS name and IP address will be shown.
If the NAS fails to create the disk volume, the following message will be shown.
Creating...
RAID5 Failed
View system information by the LCD panel
When the LCD panel shows the NAS name and IP address, you may press the “Enter” button to
enter the Main Menu. To do this, press and hold Enter for two seconds. The main menu consists of
the following menu items:
1. TCP/IP
2. Physical disk
3. Volume
4. System
5. Shut down
6. Reboot
7. Password
8. Back
TCP/IP
Menu item TCP/IP contains the follow
ing options:
1. LAN IP Address
2. LAN Subnet Mask
3. LAN Gateway
4. LAN PRI. DNS
5. LAN SEC. DNS
6. Enter Network Settings
– Network Settings – DHCP
– Network Settings – Static IP
– Network Settings – BACK
7. Back to Main Menu
i
In System Administration - Network - TCP/IP, you can configure the IP address, subnet mask,
gateway, and DNS of LAN 1 and LAN 2.
