Item no. Part no. Part name Service part
1 9322556028 Top panel assy ♦
2 9377840011 Protective net assy ♦
3 9322553201 Motor bracket assy ♦
4 9322551313 Separator assy ♦
5 9322552020 Cabinet right assy ♦
6 9322570000 Switch cover assy ♦
7 9901070013 Terminal ♦
8 9709685686 Main PCB (Service) ♦
9 9900850012 Thermistor (Outdoor temp.) ♦
10 9900935047 Thermistor assy ♦
12 9322420039 Heat sink ♦
13 9323550032 Base assy ♦
15 9300089012 Thermistor spring ♦
16 9322386007 Cushion rubber ♦
17 9319158006 Emblem ♦
18 9322315021 Front panel, painted ♦
19 9384265012 Fan guard ♦
20 9322555311 Front panel assy ♦
21 9322136008 Propeller fan ♦
22 9603553005 Brushless motor ♦
23 9322275004 Condenser total assy ♦
a — Inverter assy —
b — Hair pin cushion —
3-1. Model: ROG09KMCDN - (02-5) - 3. Outdoor unit parts list
