Fujitsu RSG09KMCDN User Manual

1. Specifications
1-1. Indoor unit
Type
Wall mounted
Inverter heat pump
Model name RSG09KMCDN RSG12KMCDN RSG14KMCDN
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Capacity
Cooling
Rated
kW 2.50 3.40 4.20
Btu/h 8,500 11,600 14,300
Min.—Max.
kW 1.0—3.8 1.0—4.2 1.2—4.65
Btu/h 3,400—13,000 3,400—14,300 4,100—15,900
Heating
Rated
kW 3.20 4.00 5.40
Btu/h 10,900 13,600 18,400
Min.—Max.
kW 0.9—5.7 0.9—5.9 0.9—6.4
Btu/h 3,100—19,400 3,100—20,100 3,100—20,400
Input power
Cooling
Rated
kW
0.540 0.800 1.100
Min.—Max. 0.21—1.08 0.21—1.25 0.26—1.25
Heating
Rated 0.720 0.960 1.400
Min.—Max. 0.18—2.35 0.18—1.8 0.185—1.9
Current
Cooling
Rated A
2.5 3.6 4.9
Heating 3.3 4.3 6.2
EER Cooling
kW/kW
4.63 4.25 3.82
COP Heating 4.44 4.17 3.86
Sensible capacity Cooling kW 2.37 2.74 3.26
Power factor
Cooling
%
94 96 97
Heating 95 97 98
Moisture removal L/h (pints/h) 0.3 (0.5) 1.1 (1.9) 1.5 (2.6)
Maximum operating current *1
Cooling
A
6.0 7.0 8.5
Heating 9.5 11.5 16.0
Fan
Airflow rate
Cooling
HIGH
m
3
/h
670 690 770
MED 530 560 600
LOW 410 450 450
QUIET 280 280 280
Heating
HIGH 750 780 820
MED 620 630 650
LOW 510 520 520
QUIET 290 290 340
Type × Q'ty Crossflow fan × 1
Motor output W 27
Sound pressure level *2
Cooling
HIGH
dB (A)
40 42 43
MED 36 37 40
LOW 30 32 33
QUIET 20 20 20
Heating
HIGH 42 43 44
MED 38 39 40
LOW 33 35 35
QUIET 22 22 24
Heat exchanger type
Dimensions (H × W × D)
mm
Main1: 210 × 670 × 26.6
Main2: 112 × 670 × 20
Sub1: 84 × 670 × 13.3
Fin pitch Man1: 1.2, Main2: 1.1, Sub1:1.4
Rows × Stages Main1: 2 × 10, Main2: 2 × 7, Sub:1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White + Pearl white (painted)
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
mm
270 × 834 × 215
Gross 277 × 914 × 332
Weight
Net
kg
10.0
Gross 13.0
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8)
Method Flare
Drain hose
Material PP+HDPE
Tip diameter mm Ø 13.8 (I.D.), Ø 15.8 to Ø 16.7 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type
Wireless (Wired, Mobile app*3 [FGLair
™
] [option])
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Maximum current is maximum value when operated within the operation range.
• *2: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
• *3: Available on Google Play
™
store or on App Store
®
. WLAN adapter is also required. For details, refer to the setting manual.
