Item no. Part no. Part name Service part
1 9322556066 Top panel assy ♦
2 9377854025 Protective net assy ♦
3 9322552099 Cabinet right assy ♦
4 9322570024 Switch cover assy ♦
5 9323550032 Base assy ♦
7 9901070013 Terminal ♦
8 9709685693 Main PCB (Service) ♦
9 9900850012 Thermistor (Outdoor temp.) ♦
10 9900935054 Thermistor assy ♦
11 9322420039 Heat sink ♦
12 9322386007 Cushion rubber ♦
13 9300089012 Thermistor spring ♦
14 9319158006 Emblem ♦
15 9322319104 Front panel, painted ♦
16 9384273017 Fan guard ♦
17 9384851000 Front panel assy ♦
18 9322150004 Propeller fan ♦
19 9603601003 Brushless motor ♦
20 9322553195 Motor bracket assy ♦
21 9317089616 Condenser total assy ♦
a — Inverter assy —
b — Hair pin cushion —
3-2. Model: ROG12KMCDN - (02-9) - 3. Outdoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
