Item no. Part no. Part name Service part
1 9322556073 Top panel assy ♦
2 9334053003 Protective net assy ♦
3 9322552082 Cabinet right assy ♦
4 9322570031 Switch cover assy ♦
5 9901070013 Terminal ♦
6 9709685709 Main PCB (Service) ♦
7 9900850012 Thermistor (Outdoor temp.) ♦
8 9900935061 Thermistor assy ♦
9 9900985011 Compressor thermistor ♦
10 9322421043 Heat sink ♦
11 9323920002 Base assy ♦
13 9322386007 Cushion rubber ♦
14 9810028006 Thermistor stopper ♦
15 9319158006 Emblem ♦
16 9384273017 Fan guard ♦
17 9322555304 Front panel assy ♦
18 9322150004 Propeller fan ♦
19 9603601003 Brushless motor ♦
20 9322553218 Motor bracket assy ♦
21 9317089630 Condenser total assy ♦
a — Inverter assy —
b — Hair pin cushion —
3-3. Model: ROG14KMCDN - (02-13) - 3. Outdoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
