Item no. Part no. Part name Service part

50 9810521002 Compressor ♦

51 9970095122 Expansion valve coil ♦

52 9322462015 Pulse motor valve assy ♦

53 9970194023 Solenoid ♦

54 9323294004 Valve assy ♦

55 9970205002 4-way valve ♦

56 9322791009 Suction pipe assy ♦

57 9383949036 Discharge pipe assy ♦

58 9322474001 2-way valve assy ♦

59 9322850010 3-way valve assy ♦

60 9324014007 S-insulator B ♦

61 9322529008 S-insulator F ♦

62 9322501004 S-insulator H ♦

63 9323045002 S-insulator V ♦

64 9322824004 S-insulator K ♦

— 9900350017 Base heater ♦

— 9313437008 Nut special assy ♦

a — Joint pipe (Condenser) —

b — Valve bracket —

c — Muffler —

d — Joint pipe (3-way valve) —

3-3. Model: ROG14KMCDN - (02-15) - 3. Outdoor unit parts list
