1. FGL remote/controller connection
2. External controller connection
Air conditioning
control system
(SET3-3)
Set temperature
objective
Thermostat OFF
conditions
Operation
(ON/OFF/Mode/
Set temperature
Fan control
Intake temperature control
Intake temperature (Room temperature)
Cooling: 18 to 30
Heating: 10 to 30
Cooling
Intake temperature < Setting temperature -0.5
Heating
Intake temperature > Setting temperature +0.5
FGL controller
Fan control commands are output from the DX kit external output terminal
Discharge temperature control
Discharge temperature
Cooling: 14 to 25
Heating: 17 to 28
Cooling
Discharge temperature < Setting temperature -5.0
Heating
Discharge temperature > Setting temperature +5.0
for 5 minutes
Air conditioning
control system
(SET3-3)
Analog input
system (SET3-2)
Temperature
Setting range
Thermostat
OFF conditions
Capacity
input range
Thermostat OFF
conditions
Operation
(ON/OFFMode/
Set temperature
When error
generated at
external equipment
Fan control
Intake temperature control
Set temperature input / Capacity input
Selection
Intake temperature (Room temperature)
Cooling: 18 to 30
Heating: 10 to 30
Cooling
Intake temperature < Setting temperature -0.5
Heating
Intake temperature > Setting temperature +0.5
0%, 5% to 100%
Controlled by external controller and EEV closed by making the capacity input 0% in cooling mode.
EEV slightly opened when the Compressor operating in heating mode
Controlled by external controller, input to DX Kit external input terminal
*Operation from FGL controller is disabled.
(Only monitoring is possible)
Wh
en fanmotor locked or another error was generated at the external equipment, the refrigerant cycle is
stopped by inputting an error signal to the DX Kit external input terminal. (EEV is Closed)
Control is perfomed by external equipment, but when you want to stop the fan during defrosting, use the
defrost signal that is output from the DX Kit external output terminal.
Outlet temperature control
Set temperature input / Capacity input
Selection
Discharge temperature
Cooling: 14 to 25
Heating: 17 to 28
Cooling
Discharge temperature < Setting temperature -5.0
Heating
Discharge temperature > Setting temperature +5.0
for 5 minutes
Capacity input Temperature setting
3-8-2 FUNDAMENTAL FUNCTIONS
03-26
