- (OP005 - 07) -
WIRED REMOTE
CONTROLLER
WIRED REMOTE
CONTROLLER
DIMENSIONS4.
120 (4-23/32)
120 (4-23/32)
21.3
(27/32)
30
(1-3/16)
45.3 (1-25/32)
12.5 (1/2)
4.5 (3/16)
4.5 (3/16)
15.3 (19/32)63.5 (2-1/2)
83.5 (3-9/32)
23
(29/32)
9 (11/32)
4.5 (3/16)
33.5
(1-5/16)
Front View Side View Rear View
Unit : mm (in.)
