１５ .TANK COVER removal
Remove the screw. (1 place) Remove the screws. (6 places)
Remove the TANK COVER (TOP). Remove the TANK COVER (SIDE).
１６ .TANK HEATER removal
Remove the TANK HEATER by hand and exchange.
Screw
Screw
Screw
Tank heater
-27-
