TABLE OF CONTENTS PAGE
1 - Special Warnings 2
Before Starting Installation 2
Mobile Home Installation 2
Recreational Park Trailers 2
2 - Product Dimensions and Cutout Requirements 3
Anti-Tip Bracket Installation 5
3 - Installation Information 7
4 - Installation Instructions 8
5 - Gas Requirement 12
Pressure Testing 13
Pressure Test Method 13
Gas Connection 14
6 Conversion for LP or NG Gas 15
Converting Appliance for Use with LP Gas 15
Replace Injectors (two ring flame burner) 15
Replace injector on (oven lower burner) 16
Converting Appliances for Use with NG Gas 18
Pressure regulator conversion 18
INJECTORS POSITION
19
Low Flame Adjustment 21
Adjustment for Burners with one or two flame
rings: 21
Adjustment for Lower Oven Burner (necessary
only for models with Thermostatic Valve): 21
Electric Gas Ignition 22
The Burner Flames 22
7 - Electrical Requirements 23
General Information 23
Electrical Connection 23
Electrical Requirements 24
IMPORTANT: Save these instructions for the local electrical
inspector use.
INSTALLER: Please leave this manual with owner for future
reference.
OWNER: Please keep this manual for future reference.
GLOSSARY OF TERMS: NG - Natural Gas
LP - Liquid Propane
Pay attention to these symbols present in this manual:
DANGER
You can be killed or seriously injured if you don’t
IMMEDIATELY follow instructions.
WARNING
This is the safety alert symbol. This symbol alerts you to
potential hazards that can kill or hurt you and others. You
can be killed or seriously injured if you don’t follow these
instructions.
READ AND SAVE THESE INSTRUCTIONS.
To installer:
Leave these instructions with the appliance.
To customer:
Retain these instructions for future reference.
WARNING
If the information in this manual is not followed exactly, a fire
or explosion may resulting in product and property damage
and / or personal injury or death.
Do not store or use gasoline or other flammable vapours and
liquids in the vicinity of this or any other appliance.
Anti-Tip Bracket Installation
WARNING
Tip Over Hazard
A child or adult can tip the range and be killed.
Ensure the anti-tip bracket is engaged when the range is
moved. Do not operate range without anti-tip bracket installed
and engaged. Failure to follow these instructions can result in
death or serious burns to children and adults.
To verify the anti-tip bracket is installed and engaged:
• Slide range forward.
• Look for the anti-tip bracket securely attached to floor or wall.
• Slide range back so rear range foot is under anti-tip bracket.
• See installation instructions for details.
Range Foot
Anti-Tip Bracket
