Fuller Brush FB-SPFM - Cleaning the Filters and Dust Cup

Warning: Always unplug the vacuum from the electrical outlet before removing the filters.
1. Remove the floor nozzle by pressing the button on the neck of the nozzle. (Fig. 14)
2. Push the dust cup latch and lift the dust cup from the vacuum. (Fig. 15)
3. Remove the filter assembly by grasping the tab inside the filter frame. (Fig. 16) Rotate the
filter frame counterclockwise and remove it from the filter assembly. Slide the foam filter off
the pleated filter. (Fig. 17)
Cleaning the Filters and Dust Cup
Fig. 15
Fig. 16 Fig. 17
Fig. 14
9
