Assembling the Vacuum
NOTE: Always unplug the vacuum before assembling or removing accessories.
1. Insert the telescoping wand into top of the main unit. Ensure the button on the
wand locks into place. (Fig. 1)
2. Attach the tool caddy to the neck of the body, then insert the crevice tool into the
caddy. (Fig. 2)
3. Attach the floor nozzle to the neck of the dust cup ensuring the button on the
nozzle neck locks into place. (Fig. 3)
4. Push the button on the telescopic wand forward to shorten or lengthen the wand
to the desired length. (Fig. 4)
Fig. 1 Fig. 2
Fig. 3 Fig. 4
6
