Cleaning the Filters and Dust Cup Continued
4. Remove the small filter from the frame inside the main unit. (Fig. 18)
5. Tap each filter on a hard surface until the dust is removed. Once a month when suction
appears to be reduced, rinse each filter in warm water or clean with a soft brush. Let each
filter completely dry for 24 hours before replacing in the vacuum. (Fig. 19)
6. Remove the dust cup from the floor nozzle to shake out remaining dust and rinse with
water. Allow to dry thoroughly before inserting filters back into the dust cup.
7. Replace the dust cup onto the vacuum. Then replace the floor nozzle and resume
vacuuming. (Fig. 20)
Warning: Do not put filters in the dishwasher or washing machine.
Fig. 20
Fig. 18 Fig. 19
