11. S peci al Usages

T he user can c onsult our compa n yif he wants to use another method insteadof the recommended

connec ting method provided in the manual, s uc h as shared DC bus.

12. Cau tion sfor Scr apof Invert er

T he e lectrolytic c apacit ors in th e ma in circuitsa nd PCB ma y explodewhen t hey are bur neda nd poisonous

gas may begenerated when the plasticparts a re burned. Please dispose t he inver ter a sindustrialrubbish.

13. AboutAppl icab le M otor

1)The sta ndard motoru sed is the 4-pole squirrel cage as ynchron ous induction m otor.If othe rkind of

motoris used,pl ease be sure to selec t th e applicable i nverter accor ding to the rated curr ent of the motor,

andpl easeconsult u s if theuser wants t he in verter t o drive the permanent magne tic synchronized motor.

2)The cooling fan of non-variable frequency mo tor isconnected to the roto rin the same bearing, s o the

cooli ng effectis weakenedif the speed is low,t hereforeuse the variable-frequency motor or install a

cooling fan in the overheat condition themotor.

3) Theinverterh as already been configured with the standardparametersfor applicable motor, please

be sure to m odify the def ault values orperf orm the moto r par amete r iden tifica tion acco rding to the

actu alconditions,otherwis e the oper ation effect or prot ection perfo rmance may be r educed.

4)Short-circ uit in thecable or motor mayca use the inverter alar m oreven d amage the i nverter.

T her efor e, please conduct the insulation short-circuittest to the cabl eand th emotor installed for the

firsttime. The short-circuit test shallalsobecar ried out in routinemaintenance.Payattention thatthe

inverter shall be separatedfrom the unit dur ingsuch test.

-5-

DZB S eri es

Chapter 1 Safe ty and Cautions

-6-

2.1 Rece iving ,S torage an d Transpo rt ation

The purposeof thischapter is to provide specific, yetsimple informa tionto , the AC drive.

This ch apt e r co ntain s in for ma ti on on the f ollowin g :

unpack install

.1 Receiving, Transportation , an d Storage

2.2 Nameplate In form ation

TheAC motor dri ve has go ne throu gh r igoro us qualit y control tests at the fac tory be fore shipment.

After receiving the AC dri v e, check for the following.

Receiving

1.Check to makesurethat t he pac kagei ncludes anAC dr ive,t he User Ma nual,dust cover sand rubber

bushings.

2.Inspe ct the unit to insure it was not damaged d uringshi pm ent.

3.Makesure tha tthe par t number indicat ed o n the nameplatecorrespond s wi th the part numberof your

order.

St orage

TheAC Drive sh oul d be kept in t he s hippi ng carton before install ation. In order to re tai n thewarranty

cove rage, theA C drive should be stored properly when itis not tobe used for a n extended periodof time.

Some storagesuggestions are:

1.Store in a clean, drylocation.

2.Store within an ambienttemperature range of -20 C to +65 C .

3.If possible, store in an air-conditio ned environme nt where the r ela tive humidity is less than

95%,non-condensi ng.

4.Do not store theACdrive i n pl ace swhere itcould be expose dto corrosive gases.

5. Please st ore theAC drive o n a shel f or on an stab lesurfa ce.

°°

Transportation

Temperature: -25 C to +70 C; R. H.: 5% to 95 %;

Air Pressure: 70 kPa to 106kPa.

°°
