FUNAI 29D-850 - Mechanical Parts List

20050808 1-16-1 HK4F8CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1X FRONT ASSEMBLY HE450ED 0VM204197
A2 CASE TOP(ANTHRACITE) HE240ED 0VM101267
A3 CHASSIS(U27F-GMBH) HE240ED 0VM000177
A4 JACK BOARD(U27 FTZ) HE480ED (See
Electrical Parts List)
A5 JACK BOARD(2-21P) HE470ED (See Electrical
Parts List)
A7 PANEL BOTTOM HE470ED 0VM203862
A10! RATING LABEL HK4F8ED ----------
A14 LABEL SERIAL NO. HE240ED or ----------
BARCODE LABEL HK4F8ED ----------
A21 WARNING LABEL HG249ED ----------
1B1 DECK ASSEMBLY CZD014/VM25E0 N25E0FL
2B5 SHEILD CYLINDER HG470ED 0VM306638
2B7 SHIELD ASSEMBLY HG470ED (See Electrical
Parts List)
2B8 BUSH LED(F) H3700UD (See Electrical Parts
List)
2B9 CUSHION HC460ED 0VM413251
2B18 FIBER TOP CASE HC460ED 0VM412906
2B46 ROHM HOLDER H7770JD (See Electrical Parts
List)
2L011 SCREW P-TIGHT 3X10 BIND HEAD+ GBCP3100
2L012 SCREW P-TIGHT 3X10 BIND HEAD+ GBCP3100
2L021 SCREW P-TIGHT M3X10 WASHER HEAD+ or GCMP3100
SCREW P-TIGHT M3*10 WASHERHEAD+ GCJP3100
2L022 SCREW P-TIGHT M3X10 WASHER HEAD+
(See Electrical Parts List) or
SCREW P-TIGHT M3*10 WASHERHEAD+ (See
Electrical Parts List)
2L031 SCREW S-TIGHT M3X6 BIND HEAD+ or GBMS3060
SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
2L041 P-TIGHT SCREW 3X8 BIND + or GBMP3080
P-TIGHT SCREW M3X8 BIND HEAD+ GBJP3080
2L042 P-TIGHT SCREW 3X8 BIND + or GBMP3080
P-TIGHT SCREW M3X8 BIND HEAD+ GBJP3080
2L051 SCREW S-TIGHT M3X5 BIND HEAD+ or GBMS3050
SCREW M3X5 HEAD+ BIND S-TIGHT GBJS3050
2L099 SCREW P-TIGHT M3X8 BIND HEAD+ GBCP3080
PACKING
S1 GIFT BOX CARTON HK4F8ED 1VM321526
S2 STYROFOAM HG470ED 0VM204516
S3 UNIT BAG V4010PA 0VM406453B
ACCESSORIES
X1 REMOTE CONTROL UNIT NA994ED NA994ED
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY R6UW/2S or XB0M311MS001
DRY BATTERY ES-GR6M-C XB0M571GLP01
X3 RF CORD PAL 1.2M or WPZ0122LG001
RF CABLE CC1001020012010 WPZ0122LW001
X4 ACCESSORY BAG E5795ED 0VM416059
X20A! OWNERS MANUAL(HU) HK4F8ED 1VMN21379
X20B! OWNERS MANUAL(CZ) HK4F8ED 1VMN21378
X20C! OWNERS MANUAL(SL) HK4F8ED 1VMN21381
X20D! OWNERS MANUAL(EN) HK4F8ED 1VMN21382
X20E! OWNERS MANUAL(GE) HK4F8ED 1VMN21383
X20F! OWNERS MANUAL(PO) HK4F8ED 1VMN21380
Ref. No. Description Part No.
