20050808 1-17-1 HK4F8EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
MCV CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
MCV CBA
Consists of the following:
1VSA11321
MAIN CBA (MCV-A)
SUB JACK CBA (MCV-B)
JACK CBA (MCV-C)
SENSOR CBA
----------
---------
----------
0VSA14893
Ref. No. Description Part No.
MAIN CBA (MCV-A)
Consists of the following:
----------
CAPACITORS
C002! METALIZED FILM CAP. 0.068µF/250V K or CT2E683DC011
! METALIZED FILM CAP. 0.068µF/250V K or CT2E683DC014
! METALIZED FILM CAP. 0.068µF/250V M CT2E683MS037
C003! SAFTY CAP. 2200pF/250V or CCN2EMA0E222
! SAFETY CAP. 2200pF/250V CA2E222MR049
C004 ELECTROLYTIC CAP. 33µF/400V M(L.Z) or CA2H330NC010
ELECTROLYTIC CAP. 33µF/400V M CE2HMZXJH330
C005 CERAMIC CAP. B K 0.01µF/500V CCD2JKP0B103
C006 CERAMIC CAP. SL K 56pF/1KV or CCD3AKPSL560
CERAMIC CAP. SL J 56pF/1KV CCD3AJPSL560
C007 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
C008 CERAMIC CAP.(AX) X K 5600pF/16V CCA1CKT0X562
C010 FILM CAP.(P) 0.022µF/50V J or CMA1JJS00223
FILM CAP.(P) 0.022µF/50V J CA1J223MS029
C011 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C012 ELECTROLYTIC CAP. 10µF/50V M H7 CE1JMAVSL100
C014 CAP ALUMINUM ELECTOLYTIC 470µF/35V M
or
CE1GMASDL471
ELECTROLYTIC CAP. 470µF/35V M CE1GMASTL471
C015 ELECTROLYTIC CAP. 47µF/25V M H7 CE1EMAVSL470
C017 CAP ALUMINUM ELECTOLYTIC 470µF/16V M
or
CE1CMASDL471
ELECTROLYTIC CAP. 470µF/16V M CE1CMASTL471
C018 CAP ALUMINUM ELECTOLYTIC 100µF/16V M
or
CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101
C020 CAP ALUMINUM ELECTOLYTIC 1000µF/16V M
or
CE1CMASDL102
ELECTROLYTIC CAP. 1000µF/16V M CE1CMZPTL102
C021 CAP ALUMINUM ELECTOLYTIC 470µF/10V M
or
CE1AMASDL471
ELECTROLYTIC CAP. 470µF/10V M CE1AMASTL471
C025 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C026 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C053 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMASSL221
C056 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C057 CHIP CERAMIC CAP.(1608) CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C060 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C061 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C157 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C158 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C251 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C252 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C253 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C254 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C302 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V or CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/25V CHD1EK30B223
C303 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C304 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C305 CHIP CERAMIC CAP. F Z 0.22µF/16V or CHD1CZ30F224
CHIP CERAMIC CAP. FZ Z 0.22µF/25V CHD1EZ3FZ224
C307 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C308 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V or CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/25V CHD1EK30B223
C309 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C310 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C311 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V or CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/25V CHD1EK30B223
C312 CHIP CERAMIC CAP. B K 8200pF/50V CHD1JK30B822
C313 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C314 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C315 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C316 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C317 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C318 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C319 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C320 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C321 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C322 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C323 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C324 CHIP CERAMIC CAP.(1608) CH J 68pF/50V or CHD1JJ3CH680
CHIP CERAMIC CAP. CG J 68pF/50V CHD1JJ3CG680
Ref. No. Description Part No.
