FUNAI 29D-850 - Page 47

20050808 1-17-3 HK4F8EL
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C506 CERAMIC CAP.(AX) B K 100pF/50V CCA1JKT0B101
C508 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C510 ELECTROLYTIC CAP. 22µF/10V M H7 CE1AMAVSL220
C511 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C512 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C513 CHIP CERAMIC CAP.(1608) CH J 22pF/50V or CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C514 CHIP CERAMIC CAP.(1608) CH J 22pF/50V or CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C515 CHIP CERAMIC CAP. CH J 18pF/50V or CHD1JJ3CH180
CHIP CERAMIC CAP. CG J 18pF/50V CHD1JJ3CG180
C516 CHIP CERAMIC CAP. CH J 18pF/50V or CHD1JJ3CH180
CHIP CERAMIC CAP. CG J 18pF/50V CHD1JJ3CG180
C517 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C518 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C519 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C520 CHIP CERAMIC CAP.(1608) CH J 100pF/50V or CHD1JJ3CH101
CHIP CERAMIC CAP.(1608) CG J 100pF/50V CHD1JJ3CG101
C521 CHIP CERAMIC CAP. CH J 560pF/50V or CHD1JJ3CH561
CHIP CERAMIC CAP. CG J 560pF/50V CHD1JJ3CG561
C522 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMASSL220
C523 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C524 CHIP CERAMIC CAP. CH J 330pF/50V or CHD1JJ3CH331
CHIP CERAMIC CAP. CG J 330pF/50V CHD1JJ3CG331
C526 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C527 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMASSL220
C528 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C530 CERAMIC CAP.(AX) F Z 0.022µF/25V CCA1EZTFZ223
C531 CERAMIC CAP.(AX) Y M 0.01µF/16V CCA1CMT0Y103
C532 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMASSL220
C533 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C535 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C538 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V or CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/25V CHD1EK30B223
C540 CAP ALUMINUM ELECTOLYTIC 470µF/6.3V M
or
CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C561 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V or CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/25V CHD1EK30B223
C562 ELECTROLYTIC CAP. 330µF/6.3V M H7 CE0KMASSL331
C563 CHIP CERAMIC CAP. F Z 1µF/10V or CHD1AZB0F105
CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C564 CHIP CERAMIC CAP.(1608) CH J 100pF/50V or CHD1JJ3CH101
CHIP CERAMIC CAP.(1608) CG J 100pF/50V CHD1JJ3CG101
C567 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C701 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V or CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C702 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C704 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C706 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C708 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C716 CHIP CERAMIC CAP. F Z 0.22µF/16V or CHD1CZ30F224
CHIP CERAMIC CAP. FZ Z 0.22µF/25V CHD1EZ3FZ224
C717 CHIP CERAMIC CAP. F Z 0.22µF/16V or CHD1CZ30F224
Ref. No. Description Part No.
CHIP CERAMIC CAP. FZ Z 0.22µF/25V CHD1EZ3FZ224
C756 CHIP CERAMIC CAP.(1608) CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C757 CHIP CERAMIC CAP.(1608) CH J 470pF/50V or CHD1JJ3CH471
CHIP CERAMIC CAP. CG J 470pF/50V CHD1JJ3CG471
C851 CHIP CERAMIC CAP.(1608) CH J 22pF/50V or CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C852 CHIP CERAMIC CAP.(1608) CH J 22pF/50V or CHD1JJ3CH220
CHIP CERAMIC CAP. CG J 22pF/50V CHD1JJ3CG220
C853 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C854 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C855 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V or CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V or CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C856 CHIP CERAMIC CAP. CH J 180pF/50V or CHD1JJ3CH181
CHIP CERAMIC CAP. CG J 180pF/50V CHD1JJ3CG181
C858 CHIP CERAMIC CAP. CH J 560pF/50V or CHD1JJ3CH561
CHIP CERAMIC CAP. CG J 560pF/50V CHD1JJ3CG561
C859 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C862 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
CONNECTOR
CN701 AFV PCB ASSEMBLY HK471AFV HK471AFV
DIODES
D001 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D002 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D003 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D004 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D005 RECTIFIER DIODE BA159 NDQZ000BA159
D006 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D007 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D008 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D009 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D011 RECTIFIER DIODE BA158 NDQZ000BA158
D012 RECTIFIER DIODE FR202-B/P NDQZ000FR202
D013 RECTIFIER DIODE FR202-B/P NDQZ000FR202
D014 SCHOTTKY BARRIER DIODE SB340 NDQZ000SB340
D015 ZENER DIODE DZ-18BSBT265 or NDTB00DZ18BS
ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D018 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D019 ZENER DIODE DZ-6.8BSBT265 or NDTB0DZ6R8BS
ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D021 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D051 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D052 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D053 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D055 PCB JUMPER D0.6-P10.0 JW10.0T
D056 ZENER DIODE DZ-5.6BSCT265 or NDTC0DZ5R6BS
ZENER DIODE MTZJT-775.6C QDTC0MTZJ5R6
D057 ZENER DIODE DZ-10BSBT265 or NDTB00DZ10BS
ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D058 ZENER DIODE DZ-18BSBT265 or NDTB00DZ18BS
ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D153 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
Ref. No. Description Part No.
