1-15-2 E9B00PIN
Notes:
Abbreviation for Active Level:
PWM -----Pulse Wide Modulation
A/D--------Analog - Digital Converter
54 -
HLF
LPF Connected
Terminal (Slicer)
55
A-
NU Not Used
BIN
COLOR-IN
SECAM or MESECAM
Chroma Video Input
Signal at Super Impose
56 -
NU Not Used
57 -
NU Not Used
58 IN
C-SYNC
Composite
Synchronized Pulse
59 OUT
8POUT-1
Control SCART 1 8Pin
Level by using 8POUT-1
and 8POUT-2
60 OUT
8POUT-2
Control SCART 1 8Pin
Level by using 8POUT-1
and 8POUT-2
61
A-
NU Not Used
BIN
SECAM-H SECAM Mode at High
62
A-
NU Not Used
BOUT
TRICK-H
Special playback = “H”
in SECAM Mode
63 OUT
SYSTEM-
RESET
System Reset Signal
64 IN
READY/
BUSY
Ready/Busy
communication Control
with Main Micro
Controller
65 OUT
S-DATA-
OUT
Communication of Data
from VCR Micro
Controller
66 IN
S-DATA-IN
Communication of Data
to VCR Micro Controller
67 OUT
S-CLOCK
Communication of Clock
with VCR Micro
Controller
68 OUT
DRV-DATA
VFD Driver IC Control
Data
69 OUT
DRV-STB
VFD Driver IC Chip
Select Signal
70 OUT
DRV-CLK
VFD Driver IC Control
Clock
71 OUT
IIC-BUS-
SCL
IIC BUS Control Clock
72
IN/
OUT
IIC-BUS-
SDA
IIC BUS Control Data
73 -
NU Not Used
74 -
NU Not Used
75
OUT P-ON-H
Power On Signal to
High
76 OUT
C-CONT
Capstan Motor Control
Signal
77 OUT
D-CONT
Drum Motor Control
Signal
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
78 OUT
C-F/R
Capstan Motor FWD/
REV Control Signal
(FWD=“L”/REV=“H”)
79 IN
S-REEL
Supply Reel Rotation
Signal
80 IN
T-R E EL
Take Up Reel Rotation
Signal
81 OUT
LM-FWD/
REV
Loading Motor Control
Signal
82 OUT
OUTPUT-
SELECT
Output Select
83 OUT
VCR-
AUDIO-
MUTE
Audio Mute Control
Signal (Mute = “H”)
84 OUT
C-POW-SW
Capstan Power
Switching Signal
85 IN
VCR POW-
SAFETY
VCR Power Supply
Safety Signal
86 IN
A-MODE
Hi-Fi Tape Detection
Signal
87 IN
C-FG
Capstan Motor Rotation
Detection Pulse
88 -
AMPVss AMPVss
89 IN
DVD-POW-
SAFETY
Abnormal Voltage
Detection
90
IN
D-PFG
Drum Motor Phase/
Frequency Generator
91 -
AMPVREF
out
V-Ref for CTL AMP
92 -
AMPVREF
in
V-Ref for CTL AMP
93 -
P80/C P80/C Terminal
94
IN/
OUT
CTL (-)
Playback/Record
Control Signal (-)
95
IN/
OUT
CTL (+)
Playback/Record
Control Signal (+)
96 -
AMPC
CTL AMP Connected
Ter minal
97 -
CTL
To Monitor for CTL AMP
Output
98 -
AMPVcc AMPVcc
99 -
AVcc
A/D Converter Power
Input/ Standard Voltage
Input
100 IN
AGC
IF AGC Comparator
Signal
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
