FUNAI DRV-A3635 - IC612 (FIP DRIVER) Pin Functions

1-15-3 E9B00PIN
IC612 ( FIP DRIVER )
Pin
No.
IN/
OUT
Signal
Name
Name Function
1 OUT
POWER-
LED
Power LED Signal Output
2 OUT VCR-LED
VCR Mode LED Signal
Output
3 OUT DVD-LED
DVD Mode LED Signal
Output
4 -
NU
Not Used
5 IN OSC
Oscillator Input
6 -
NU
Not Used
7 IN DRV-DIN
Serial Data Input
8 IN DRV-CLK
Clock Input
9 IN DRV-STB
Serial Interface Strobe
10 -
NU
Not Used
11 -
NU
Not Used
12 - VSS
GND
13 - VDD
Power Supply
14 -
NU
Not Used
15 -
NU
Not Used
16 -
NU
Not Used
17 -
NU
Not Used
18 -
NU
Not Used
19 -
NU
Not Used
20
OUT
c
Segment Output
21 b
22 a
23 d
24 e
25 f
26 i
27 h
28 g
29 -
NU
Not Used
30 - VEE
Pull Down Level
31 -
NU
Not Used
32 -
NU
Not Used
33 -
NU
Not Used
34 -
NU
Not Used
35 -
NU
Not Used
36
OUT
7G
Grid Output
37 6G
38 5G
39 4G
40 3G
41 2G
42 1G
43 - VDD
Power Supply
44 - VSS
GND
Pin
No.
IN/
OUT
Signal
Name
Name Function
