FUNAI DRV-C3835 - Page 70

20050417 1-19-2 E9B00EL
C337 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C339 CHIP CERAMIC CAP. CH J 120pF/50V CHD1JJ3CH121
C340 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C341 CHIP CERAMIC CAP.(1608) CH D 10pF/
50V
CHD1JD3CH100
C342 CHIP CERAMIC CAP.(1608) CH J
1000pF/50V
CHD1JJ3CH102
C343 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C344 ELECTROLYTIC CAP. 4.7µF/25V M NP
H7
CP1EMAVSB4R7
C345 ELECTROLYTIC CAP. 0.47µF/50V M H7
or
CE1JMAVSLR47
ALUMINUM ELECTROLYTIC CAP
0.47µF/50V H7
CE1JMAVSMR47
C347 CHIP CERAMIC CAP.(1608) B K 0.1µF/
25V or
CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/
16V
CHD1CK30B104
C349 ELECTROLYTIC CAP. 0.47µF/50V M H7
or
CE1JMAVSLR47
ALUMINUM ELECTROLYTIC CAP
0.47µF/50V H7
CE1JMAVSMR47
C350 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C370 B CERAMIC CAP.(AX) Y M 0.01µF/16V CCA1CMT0Y103
C371 B CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
B CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C372 B CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
B CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C373 B CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
B CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C374 B CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
B CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C375 B CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C376 B CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
B CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C377 B CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C378 B CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C379 B ELECTROLYTIC CAP. 0.47µF/50V M H7
or
CE1JMAVSLR47
B ALUMINUM ELECTROLYTIC CAP
0.47µF/50V H7
CE1JMAVSMR47
C381 B CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
B CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C382 B CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C383 B CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C384 B ELECTROLYTIC CAP. 2.2µF/50V M H7 or CE1JMAVSL2R2
B ALUMINUM ELECTROLYTIC CAP 2.2µF/
50V H7
CE1JMAVSM2R2
C402 FILM CAP.(P) 0.018µF/50V J or CMA1JJP00183
FILM CAP.(P) 0.018µF/50V J CA1J183MS029
C403 CERAMIC CAP. B K 470pF/100V CCD2AKS0B471
C404 ELECTROLYTIC CAP. 220µF/6.3V M H7
or
CE0KMASSL221
ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMASSM221
C405 ELECTROLYTIC CAP. 47µF/6.3V M H7 or CE0KMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/
6.3V H7
CE0KMAVSM470
Ref. No. Mark Description Part No.
C407 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C408 CHIP CERAMIC CAP. B K 1800pF/50V CHD1JK30B182
C409 CHIP CERAMIC CAP.(1608) CH J 33pF/
50V
CHD1JJ3CH330
C410 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C411 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C412 ELECTROLYTIC CAP. 33µF/6.3V M H7 or CE0KMAVSL330
ALUMINUM ELECTROLYTIC CAP 33µF/
6.3V H7
CE0KMAVSM330
C413 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C414 CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C415 ELECTROLYTIC CAP. 4.7µF/25V M H7 or CE1EMAVSL4R7
ALUMINUM ELECTROLYTIC CAP 4.7µF/
25V H7
CE1EMAVSM4R7
C416 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C417 ELECTROLYTIC CAP. 22µF/6.3V M H7 or CE0KMAVSL220
ALUMINUM ELECTROLYTIC CAP 22µF/
6.3V H7
CE0KMAVSM220
C418 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C419 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C421 ELECTROLYTIC CAP. 47µF/6.3V M H7 or CE0KMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/
6.3V H7
CE0KMAVSM470
C451 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C452 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C453 ELECTROLYTIC CAP. 22µF/10V M H7 or CE1AMAVSL220
ALUMINUM ELECTROLYTIC CAP 22µF/
10V H7
CE1AMAVSM220
C454 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C455 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C456 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C457 ELECTROLYTIC CAP. 4.7µF/25V M H7 or CE1EMAVSL4R7
ALUMINUM ELECTROLYTIC CAP 4.7µF/
25V H7
CE1EMAVSM4R7
C458 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C461 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C462 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C463 ELECTROLYTIC CAP. 22µF/10V M H7 or CE1AMAVSL220
ALUMINUM ELECTROLYTIC CAP 22µF/
10V H7
CE1AMAVSM220
C464 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C465 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C466 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C467 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
Ref. No. Mark Description Part No.
