FUNAI DRV-C3835 - Page 71

20050417 1-19-3 E9B00EL
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C468 ELECTROLYTIC CAP. 220µF/6.3V M H7
or
CE0KMAVSL221
ALUMINUM ELECTROLYTIC CAP
220µF/6.3V H7
CE0KMAVSM221
C469 ELECTROLYTIC CAP. 22µF/10V M H7 or CE1AMAVSL220
ALUMINUM ELECTROLYTIC CAP 22µF/
10V H7
CE1AMAVSM220
C470 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C471 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C472 ELECTROLYTIC CAP. 4.7µF/25V M H7 or CE1EMAVSL4R7
ALUMINUM ELECTROLYTIC CAP 4.7µF/
25V H7
CE1EMAVSM4R7
C473 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C474 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C475 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C476 ELECTROLYTIC CAP. 22µF/6.3V M H7 or CE0KMAVSL220
ALUMINUM ELECTROLYTIC CAP 22µF/
6.3V H7
CE0KMAVSM220
C477 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C478 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C479 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C480 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C481 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C482 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C483 ELECTROLYTIC CAP. 4.7µF/25V M H7 or CE1EMAVSL4R7
ALUMINUM ELECTROLYTIC CAP 4.7µF/
25V H7
CE1EMAVSM4R7
C484 ELECTROLYTIC CAP. 4.7µF/25V M H7 or CE1EMAVSL4R7
ALUMINUM ELECTROLYTIC CAP 4.7µF/
25V H7
CE1EMAVSM4R7
C485 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
ALUMINUM ELECTROLYTIC CAP 10µF/
16V H7
CE1CMAVSM100
C486 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C487 ELECTROLYTIC CAP. 47µF/16V M H7 or CE1CMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/
16V H7
CE1CMAVSM470
C488 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C502 CHIP CERAMIC CAP.(1608) B K 0.022µF/
50V or
CHD1JK30B223
CHIP CERAMIC CAP.(1608) B K 0.022µF/
25V
CHD1EK30B223
C505 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C506 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C507 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
Ref. No. Mark Description Part No.
C508 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C509 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C510 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C511 CHIP CERAMIC CAP.(1608) CH J 100pF/
50V
CHD1JJ3CH101
C512 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C514 CHIP CERAMIC CAP. B K 330pF/50V CHD1JK30B331
C515 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C516 ELECTROLYTIC CAP. 22µF/6.3V M H7 or CE0KMAVSL220
ALUMINUM ELECTROLYTIC CAP 22µF/
6.3V H7
CE0KMAVSM220
C517 CERAMIC CAP.(AX) F Z 0.022µF/25V CCA1EZTFZ223
C518 ELECTROLYTIC CAP. 22µF/6.3V M H7 or CE0KMAVSL220
ALUMINUM ELECTROLYTIC CAP 22µF/
6.3V H7
CE0KMAVSM220
C519 CHIP CERAMIC CAP. CH J 560pF/50V CHD1JJ3CH561
C521 ELECTROLYTIC CAP. 22µF/6.3V M H7 or CE0KMAVSL220
ALUMINUM ELECTROLYTIC CAP 22µF/
6.3V H7
CE0KMAVSM220
C522 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C524 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C527 CERAMIC CAP.(AX) B K 100pF/50V CCA1JKT0B101
C531 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C533 CHIP CERAMIC CAP.(1608) B K 0.047µF/
50V or
CHD1JK30B473
CHIP CERAMIC CAP.(1608) B K 0.047µF/
25V
CHD1EK30B473
C534 ELECTROLYTIC CAP. 47µF/6.3V M H7 or CE0KMAVSL470
ALUMINUM ELECTROLYTIC CAP 47µF/
6.3V H7
CE0KMAVSM470
C535 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C536 B CHIP CERAMIC CAP. CH J 560pF/50V CHD1JJ3CH561
C538 CHIP CERAMIC CAP. CH J 180pF/50V CHD1JJ3CH181
C539 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C540 CHIP CERAMIC CAP.(1608) B K 4700pF/
50V
CHD1JK30B472
C541 CHIP CERAMIC CAP. CH J 18pF/50V CHD1JJ3CH180
C542 CHIP CERAMIC CAP. CH J 18pF/50V CHD1JJ3CH180
C543 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C544 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C545 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C546 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C547 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C548 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C549 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
ALUMINUM ELECTROLYTIC CAP 1µF/
50V H7
CE1JMAVSM1R0
C550 ELECTROLYTIC CAP. 100µF/6.3V H7 or CE0KMAVSL101
ALUMINUM ELECTROLYTIC CAP
100µF/6.3V H7
CE0KMAVSM101
C553 ELECTROLYTIC CAP. 22µF/10V M H7 or CE1AMAVSL220
ALUMINUM ELECTROLYTIC CAP 22µF/
10V H7
CE1AMAVSM220
C554 ELECTROLYTIC CAP. 100µF/6.3V H7 or CE0KMAVSL101
Ref. No. Mark Description Part No.
