FUNAI DRV-C3835 - Page 81

20050417 1-19-13 E9B00EL
POWER SW CBA
FUNCTION CBA
FRONT JACK CBA
SENSOR CBA
PSV CBA
POWER SUPPLY CBA
2B17 NEW SHIELD ASSEMBLY H9700ED 1VM420438
2B46 ROHM HOLDER H7770JD 0VM304573
FL601 VACUUM FLUORESCENT DISPLA 7-BT-
301NS
TVFD1C0FT049
JK1502 RGB CONNECTOR MRC-021V-05
ABS(B110
JXGL210LY008
JK1503 FIBER OPTIC TRANS.MODULE 0C-
0805T*002 or
JWHHA00JD002
OPTICAL TRANSMITTING MODULE
JST1162
JWHHA00SLT01
JK1504 RCA JACK MSP-281V41-B(B110) JXRL010LY140
JK1505 RCA JACK MSP-382V-12 NILF JXRL020LY120
JK1506 S TYPE JACK MDC-050V-2.4 LF(B110 or JXEL040LY003
S TYPE JACK DIN-425-01 JXEL040YUQ01
JW101 FFC CABLE 30P FFC/P1.00/140 WX1E9B00-003
JW102 FFC CABLE 30P FFC/P1.00/140 WX1E9B00-003
RM1501 REMOTE RECEIVER MIM-93M6DKF or USESJRSUNT01
REMOTE RECEIVER PIC-37042LU USESJRSKK033
PS502 PHOTO INTERRUPTER RPI-302C70 QPWZP1302C70
TP301 PCB JUMPER D0.6-P11.5 JW11.5T
TP501 PCB JUMPER D0.6-P5.0 JW5.0T
TP502 PCB JUMPER D0.6-P7.0 JW7.0T
TP503 PCB JUMPER D0.6-P7.5 JW7.5T
TP504 PCB JUMPER D0.6-P28.0 JW28.0T
TU1501 A TUNER UNIT TMFE2-301A UTUNPLGAL017
TU1501 B TUNER UNIT TMFE2-401A UTUNPSLAL005
VR501 CARBON P.O.T. VZ067TL1 B104 PB(F) VRCB104HH014
X301 XTAL 4.433619MHz or FXC445LLN004
XTAL 1K*044334EE FXC445LDS002
X501 QUARTS CRYSTAL 12.000000MHz or FXD126LCHE01
XTAL 12MHz 12.000MHz FXD126LDS002
X502 XTAL QTF38-32768K125P20L or FXC323LQUA02
XTAL 32.768kHz(20PPM) FXC323LDS002
Ref. No. Mark Description Part No.
POWER SW CBA (MCV-B)
Consists of the following:
----------
DIODE
D671 LED(RED) 204HD/E NPQZ00204HDE
SWITCHES
SW671 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
MISCELLANEOUS
JW001 FLAT CABLE 4P AWG26#2651/P2.0/100 WX1E9B00-007
Ref. No. Mark Description Part No.
FUNCTION CBA (MCV-C)
Consists of the following:
----------
SWITCHES
SW681 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW682 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
MISCELLANEOUS
JW002 FLAT CABLE 3P AWG26#2651/P2.0/80 WX1E9B00-004
Ref. No. Mark Description Part No.
FRONT JACK CBA (MCV-D)
Consists of the following:
----------
CAPACITORS
C1205 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
Ref. No. Mark Description Part No.
C1206 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
CONNECTOR
CN1201 FE CONNECTOR TOP 8P 08FE-BT-VK-N JCFEJ08JG001
RESISTORS
R1201 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R1202 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R1203 CHIP RES. 1/10W J 220 Ω or RRXAJR5Z0221
RES CHIP 1608 1/10W J 220 Ω RRXA221YF002
R1204 CHIP RES. 1/10W J 220 Ω or RRXAJR5Z0221
RES CHIP 1608 1/10W J 220 Ω RRXA221YF002
R1205 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
MISCELLANEOUS
JK1201 RCA JACK(YELLOW) MTJ-032-11B-40
FE01
JXRL010LY101
JK1202 RCA JACK(WHITE) MTJ-032-11B-41
FE01
JXRL010LY102
JK1203 RCA JACK(RED) MTJ-032-11A-31 FE01 JYRL010LY024
JK1204 S TYPE JACK MDC-050V-2.4 LF(B110 or JXEL040LY003
S TYPE JACK DIN-425-01 JXEL040YUQ01
JW103 FFC CABLE 8P FFC/P1.25/120 WX1E9700-002
Ref. No. Mark Description Part No.
SENSOR CBA
Consists of the following:
1VSA11699
TRANSISTORS
Q503 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Q504 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Ref. No. Mark Description Part No.
PSV CBA
Consists of the following:
1VSA14483
POWER SUPPLY CBA (PSV-A)
JUNCTION CBA (PSV-B)
REAR JACK CBA (PSV-C)
----------
----------
----------
Ref. No. Mark Description Part No.
POWER SUPPLY CBA (PSV-A)
Consists of the following:
----------
CAPACITORS
C013 ELECTROLYTIC CAP. 10µF/50V M or CE1JMASDL100
ALUMINUM ELECTROLYTIC CAP 10µF/
50V M
CE1JMASTM100
C014 ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
ELECTROLYTIC CAP. 470µF/16V M CE1CMASTM471
C015 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTM101
C017 ELECTROLYTIC CAP. 4700µF/6.3V SL or CE0KMZADL472
ELECTROLYTIC CAP. 4700µF/6.3V SM or CE0KMZPDL472
ALUMINUM ELECTROLYTIC CAP
4700µF/6.3V M
CE0KMZPTM472
C018 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTM471
C020 ELECTROLYTIC CAP. 22µF/50V M or CE1JMASDL220
ELECTROLYTIC CAP 22µF/50V M CE1JMASTM220
C022 ELECTROLYTIC CAP. 470µF/35V M or CE1GMASDL471
ELECTROLYTIC CAP. 470µF/35V M CE1GMASTM471
C1001! METALIZED FILM CAP. 0.068µF/250V K
or
CT2E683DC011
! METALIZED FILM CAP. 0.068µF/250V K
or
CT2E683DC014
Ref. No. Mark Description Part No.
