20050417 1-19-14 E9B00EL
! METALIZED FILM CAP. 0.068µF/250V M CT2E683MS037
C1004 ELECTROLYTIC CAP. 100µF/400V M CA2H101S6016
C1005 CERAMIC CAP. SL K 56pF/1KV or CCD3AKPSL560
CERAMIC CAP. SL J 56pF/1KV CCD3AJPSL560
C1006! SAFTY CAP. 2200pF/250V or CCN2EMA0E222
! SAFETY CAP. 2200pF/250V CA2E222MR049
C1007 ELECTROLYTIC CAP. 1000µF/6.3V M or CE0KMASDL102
ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASTM102
C1013 CERAMIC CAP.(AX) B J 1000pF/50V CCA1JJT0B102
C1018 ELECTROLYTIC CAP. 100µF/10V M or CE1AMASDL101
ELECTROLYTIC CAP. 100µF/10V M CE1AMASTM101
C1021 CERAMIC CAP.(AX) Y M 0.01µF/16V CCA1CMT0Y103
C1025 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1029 CERAMIC CAP.(AX) X K 1800pF/16V CCA1CKT0X182
C1032 ELECTROLYTIC CAP. 10µF/16V M or CE1CMASDL100
ELECTROLYTIC CAP. 10µF/16V M CE1CMASTM100
C1033 CERAMIC CAP. YV Z 0.022µF/50V CCD1JZSYV223
C1035 ELECTROLYTIC CAP. 3300µF/6.3V SL or CE0KMZADL332
ELECTROLYTIC CAP. 3300µF/6.3V SM or CE0KMZPDL332
ALUMINUM ELECTROLYTIC CAP
3300µF/6.3V M
CE0KMZPTM332
C1036 CERAMIC CAP. B K 470pF/500V CCD2JKP0B471
C1037 ELECTROLYTIC CAP. 1000µF/16V M or CE1CMASDL102
ALUMINUM ELECTROLYTIC CAP
1000µF/16V M
CE1CMASTM102
C1039 ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
ELECTROLYTIC CAP. 470µF/16V M CE1CMASTM471
C1106 ELECTROLYTIC CAP. 100µF/35V M or CE1GMASDL101
ELECTROLYTIC CAP. 100µF/35V M CE1GMASTM101
C2014 CERAMIC CAP. B K 0.01µF/500V CCD2JKP0B103
DIODES
D013 RECTIFIER DIODE BA158 or NDQZ000BA158
RECTIFIER DIODE BA158 NDWZ000BA158
D014 SCHOTTKY BARRIER DIODE SB190 or NDQZ000SB190
SCHOTTKY BARRIER DIODE SB190 NDWZ000SB190
D016 SCHOTTKY BARRIER DIODE SB340 or NDQZ000SB340
SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
D017 ZENER DIODE DZ-15BSCT265 or NDTC00DZ15BS
ZENER DIODE MTZJT-7715C QDTC00MTZJ15
D018 RECTIFIER DIODE BA158 or NDQZ000BA158
RECTIFIER DIODE BA158 NDWZ000BA158
D019 RECTIFIER DIODE FR203-B/P NDQZ000FR203
D1001 DIODE 1N5397-B NDLZ001N5397
D1002 DIODE 1N5397-B NDLZ001N5397
D1003 DIODE 1N5397-B NDLZ001N5397
D1004 DIODE 1N5397-B NDLZ001N5397
D1006 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1008 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1011 RECTIFIER DIODE BA159 or NDQZ000BA159
RECTIFIER DIODE BA159 NDWZ000BA159
D1012 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1016 RECTIFIER DIODE FR101 NDWZ000FR101
D1017 ZENER DIODE DZ-18BSBT265 or NDTB00DZ18BS
ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D1018 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1019 ZENER DIODE DZ-6.8BSBT265 or NDTB0DZ6R8BS
ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D1022 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1023 PCB JUMPER D0.6-P5.0 JW5.0T
D1024 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1025 SWITCHING DIODE 1N4148M or NDTZ01N4148M
Ref. No. Mark Description Part No.
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1030 SCHOTTKY BARRIER DIODE SB240-B/
P
NDWZ000SB240
D1031 SCHOTTKY BARRIER DIODE SB390 or NDQZ000SB390
SCHOTTKY BARRIER DIODE SB390 NDWZ000SB390
D1032 SCHOTTKY BARRIER DIODE SB340 or NDQZ000SB340
SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
ICS
IC1001
!
PHOTOCOUPLER EL817A or NPEA000EL817
! PHOTOCOUPLER EL817B or NPEB000EL817
! PHOTOCOUPLER EL817C or NPEC000EL817
! PHOTOCOUPLER LTV-817B-F or NPEB0LTV817F
! PHOTOCOUPLER LTV-817C-F or NPEC0LTV817F
! PHOTOCOUPLER PS2561A-1(Q) or QPEQPS2561A1
! PHOTOCOUPLER PS2561A-1(W) QPEWPS2561A1
COILS
L010 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS(PB FREE)
LGB0810TLF-470K
LLBD00PU6010
L013 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS(PB FREE)
LGB0810TLF-470K
LLBD00PU6010
L1001 BEAD CORE ASSEMBLY E9770ED 1VSA12652
L1002 BEAD CORE ASSEMBLY E9770ED 1VSA12652
L1003! LINE FILTER 56MH TLF14CB5630R2 or LLBG00ZTU022
! LINE FILTER 50MH LF-4D-E503(PB
FREE)
LLBG00ZKQ014
L1004 BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
L1005 BEAD CORE ASSEMBLY E9770ED 1VSA12652
L1011 CHOKE COIL 47µH or LLBD00PKV022
RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH-K or LLBD00PKT001
FIXED INDUCTORS(PB FREE)
LGB0810TLF-470K
LLBD00PU6010
L1013 POWER INDUCTORS TWKBNP-180K or LLC180KKV007
CHOKE COIL(18µH) LHL10NB180K or LLARKGQTU180
POWER INDUCTORS CWKBNP-180K LLF1800KV002
TRANSISTORS
Q1001! FET 2SK3566 QFWZ02SK3566
Q1003 TRANSISTOR 2SC1815-Y(TE2 F T) QQSY2SC1815F
Q1004 TRANSISTOR KTA1267-Y-AT/P or NQSYKTA1267P
TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q1008 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
RESISTORS
R057 CHIP RES. 1/10W J 220k Ω or RRXAJR5Z0224
RES CHIP 1608 1/10W J 220k Ω RRXA224YF002
R1002 CARBON RES. 1/4W J 560k Ω RCX4JATZ0564
R1003 CARBON RES. 1/4W J 560k Ω RCX4JATZ0564
R1004 METAL OXIDE FILM RES. 2W J 82k Ω or RN02JZLZ0823
METAL OXIDE FILM RES. 2W J 82k Ω or RN02JZQZ0823
METAL OXIDE FILM RES. 2W J 82k Ω RN02JZPZ0823
R1005 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1006 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1007 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1008 CARBON RES. 1/4W G 820 Ω RCX4GATZ0821
R1010 CARBON RES. 1/6W J 22k Ω or RCX6JATZ0223
CARBON RES. 1/4W J 22k Ω RCX4JATZ0223
R1011 METAL OXIDE FILM RES. 1W J 1.3 Ω or RN01JZLZ01R3
METAL OXIDE FILM RES. 1W J 1.3 Ω or RN01JZQZ01R3
Ref. No. Mark Description Part No.
