20050417 1-19-15 E9B00EL
JUNCTION CBA
REAR JACK CBA
METAL OXIDE FILM RES. 1W J 1.3 Ω RN01JZPZ01R3
R1020 CARBON RES. 1/6W J 1.8k Ω or RCX6JATZ0182
CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R1021 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R1022 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R1023 CHIP RES.(1608) 1/10W F 2.2k Ω or RRXAFR5H0222
CHIP RES. 1/10W F 2.2k Ω or RRXAFR5Z0222
RES CHIP 1608 1/10W F 2.20k Ω RTW2201YF002
R1024 CHIP RES. 1/10W J 68k Ω or RRXAJR5Z0683
RES CHIP 1608 1/10W J 68k Ω RRXA683YF002
R1025 CHIP RES. 1/10W F 5.6k Ω or RRXAFR5H0562
CHIP RES. 1/10W F 5.6k Ω or RRXAFR5Z0562
RES CHIP 1608 1/10W F 5.60k Ω RTW5601YF002
R1029 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1032 CARBON RES. 1/6W J 2.2k Ω or RCX6JATZ0222
CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
R1035 CARBON RES. 1/6W J 1k Ω or RCX6JATZ0102
CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1036 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1037 CARBON RES. 1/6W J 10k Ω or RCX6JATZ0103
CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R1038 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1039 CARBON RES. 1/6W J 470k Ω or RCX6JATZ0474
CARBON RES. 1/4W J 470k Ω RCX4JATZ0474
R1040 CARBON RES. 1/4W J 8.2 Ω RCX4JATZ08R2
R1041 CARBON RES. 1/4W J 5.6 Ω RCX4JATZ05R6
R1043 METAL OXIDE FILM RES. 1W J 2.7 Ω or RN012R7ZU001
METAL OXIDE FILM RES. 1W J 2.7 Ω or RN012R7KE009
METAL OXIDE FILM RES. 1W J 2.7 Ω RN012R7DP003
R1059 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1126 CHIP RES. 1/10W J 33k Ω or RRXAJR5Z0333
RES CHIP 1608 1/10W J 33k Ω RRXA333YF002
MISCELLANEOUS
2B18 HEAT SINK E6800ED 1VM420987
2L019 SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
AC1001
!
AC CORD PE8G2CG9G0AB05 WAE0172LW011
F1001! FUSE T1.6AL/250V or PAGC20BW3162
! FUSE 50T016H 1.6A/250V PAGH20BHV162
FH1001 FUSE HOLDER MSF-015 LF (B110) or XH01Z00LY002
FUSE HOLDER DFH-001 XH01Z00RP001
FH1002 FUSE HOLDER MSF-015 LF (B110) or XH01Z00LY002
FUSE HOLDER DFH-001 XH01Z00RP001
T0011! TRANS POWER 6711 or LTTZPE0KT007
! TRANS POWER BCK-28-9985 LTTZPE0XB006
Ref. No. Mark Description Part No.
JUNCTION CBA (PSV-B)
Consists of the following:
----------
CONNECTOR
CN051A 242 SERIES CONNECTOR TUC-P19X-
B1 WHT ST
JCTUB19TG002
MISCELLANEOUS
JW1001 FLAT CABLE 10P AWG26#2651/P2.0/100 WX1E9700-003
JW1002 FLAT CABLE 9P AWG26#2651/P2.0/100 WX1E9700-004
Ref. No. Mark Description Part No.
Ref. No. Mark Description Part No.
REAR JACK CBA (PSV-C)
Consists of the following:
----------
CAPACITORS
C2003 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2004 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2005 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2006 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2007 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2008 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JKB0B102
C2009 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C2010 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C2011 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JKB0B102
C2012 ELECTROLYTIC CAP. 1µF/50V M or CE1JMASDL1R0
ELECTROLYTIC CAP 1µF/50V M CE1JMASTM1R0
C2013 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JKB0B102
DIODES
D2001 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2002 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2003 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2004 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2005 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2006 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2007 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2008 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2009 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
D2010 ZENER DIODE DZ-11BSAT265 or NDTA00DZ11BS
ZENER DIODE MTZJT-7711A QDTA00MTZJ11
COILS
L2001 BEAD CORE ASSEMBLY E9770ED ----------
PCB JUMPER D0.6-P35.0 JW35.0T
BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
TRANSISTORS
Q2002 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
Q2003 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
RESISTORS
R2003 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R2004 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R2005 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R2006 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R2007 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R2008 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R2009 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R2010 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R2011 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R2012 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
www.freeservicemanuals.info
Digitized in Heiloo Netherlands
To Next Page
