1-16-2 E9G01PIN
59 OUT
8POUT-1
Control SCART 1 8Pin Level
by using 8POUT-1 and
8POUT-2
60 OUT
8POUT-2
Control SCART 1 8Pin Level
by using 8POUT-1 and
8POUT-2
61 -
NU Not Used
62 -
NU Not Used
63 OUT
SYSTEM-
RESET
System Reset Signal
64 IN
READY/
BUSY
Ready/Busy communication
Control with Main Micro
Controller
65 OUT
S-DATA-
OUT
Communication of Data from
VCR Micro Controller
66 IN
S-DATA-IN
Communication of Data to
VCR Micro Controller
67 OUT
S-CLOCK
Communication of Clock with
VCR Micro Controller
68 OUT
DRV-DATA VFD Driver IC Control Data
69 OUT
DRV-STB
VFD Driver IC Chip Select
Signal
70 OUT
DRV-CLK VFD Driver IC Control Clock
71 OUT
IIC-BUS
SCL
IIC BUS Serial Clock
72
IN/
OUT
IIC-BUS
SDA
IIC BUS Serial Data
73 -
NU Not Used
74 -
NU Not Used
75
OUT P-ON-H Power On Signal to High
76 OUT
C-CONT Capstan Motor Control Signal
77 OUT
D-CONT Drum Motor Control Signal
78 OUT
C-F/R
Capstan Motor FWD/REV
Control Signal (FWD=“L”/
REV=“H”)
79 IN
S-REEL Supply Reel Rotation Signal
80 IN
T-REEL Take Up Reel Rotation Signal
81 OUT
LM-FWD/
REV
Loading Motor Control Signal
82 OUT
OUTPUT-
SELECT
Output Select
83 OUT
VCR-
AUDIO-
MUTE
Audio Mute Control Signal
(Mute = “H”)
84 OUT
C-POW-SW
Capstan Power Switching
Signal
85 IN
VCR-POW-
SAFETY
VCR Power Supply Safety
Signal
86 IN
A-MODE Hi-Fi Tape Detection Signal
87 IN
C-FG
Capstan Motor Rotation
Detection Pulse
88 -
AMPVss Ground
Pin
No.
IN/
OUT
Signal
Name
Function
89 IN
DVD-POW-
SAFETY
DVD Power Supply Safety
Signal
90
IN
D-PFG
Drum PG/FG Input Signal
91 -
AMPVREF
out
V-Ref for CTL AMP
92 -
AMPVREF
in
V-Ref for CTL AMP
93 -
P80/C P80/C Terminal
94
IN/
OUT
CTL (-)
Playback/Record Control
Signal (-)
95
IN/
OUT
CTL (+)
Playback/Record Control
Signal (+)
96 -
AMPC
CTL AMP Connected
Ter mina l
97 -
CTL
To Monitor for CTL AMP
Output
98 -
AMPVcc
Always +5V with AC Plug
Connected
99 -
AVcc
Always +5V with AC Plug
Connected
100 IN
AGC IF AGC Comparator Signal
Pin
No.
IN/
OUT
Signal
Name
Function
