FUNAI DRVR-B778S - Mechanical Parts List

20070608 1-19-1 E9G01CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1X FRONT ASSEMBLY E9G01BD 1VM223078
A2 TOP COVER E9G00ED 1VM223085
A3 MAIN CHASSIS E9400UD 0VM101353J
A4 REAR PANEL E9G01BD 1VM223072
A10! RATING LABEL E9G01BD ----------
A14 BARCODE LABEL UNFIGURE E9704ED or ----------
BARCODE LABEL E9G01BD ----------
A34 FOOT H5100UD 0VM406940A
1B1 DECK ASSEMBLY CZD014/VM25E0 N25E0FL
2B1 DECK PEDESTAL E9600UD 1VM120055G
2B2 FRONT BRACKET E9400UD 0VM204534C
2B3 FRONT BRACKET R E9400UD 0VM416269A
2B4 EARTH PLATE E9H10UD 1VM425084
2B10 PCB HOLDER E9H10UD 1VM121066F
2B13 JACK BRACKET E9400UD 0VM416273
2B31 TAPE HIMELON H9206JD 0VM413956
2B45 DUST COVER(R4 PAL) E9GA0BD 1VM323812A
2B59 JACK EARTH PLATE E9600UD 1VM320623
2B76 RUBBER CUSHION(B) E9B00ED 1VM424744
2B77 RUBBER CUSHION(C) E9B00ED 1VM424745
2B84 FAN HOLDER E9H10UD 1VM323512
2B87 PCB WASHER E9H10UD 1VM425701
2L011 SCREW TAP TIGHT M3X5 BIND HEAD+BLK NI GBHC3050
2L013 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L014 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L017 SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
2L021 SCREW P-TIGHT M3X8 BIND HEAD+ GBCP3080
2L022 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L030 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L033 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
2L043 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L044 SCREW S-TIGHT M3X8 BIND HEAD+ GBJS3080
2L045 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L052 SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
2L054 SCREW P-TIGHT M3X6 BIND HEAD+ GBJP3060
2L060 SCREW P-TIGHT M3X8 BIND HEAD+ GBJP3080
2L062 SCREW B-TIGHT M3X8 BIND HEAD+ GBHB3080
2L071 SCREW P-TIGHT M3*10 WASHERHEAD+ GCJP3100
2L075 SCREW P-TIGHT M3X8 BIND HEAD+ BLK GBHP3080
2L081 S-TIGHT SCREW M3X6 BIND HEAD+BLACK GBHS3060
2L082 S-TIGHT SCREW M3X6 BIND HEAD+BLACK GBHS3060
2L083 SCREW P-TIGHT M3X8 BIND HEAD+ BLK GBHP3080
2L111 SCREW P-TIGHT 3X14 BIND HEAD + GBJP3140
FM1001 MOTOR DC FAN 2D65BK100100 MMEZR12XNR01
PACKING
S1 GIFT BOX CARTON E9G01BD 1VM323978
S2 SIDE PAD E9701BD 1VM120075
S3 SET BAG E7708UA 0DM400731D
S5 PAD E9GA0BD 1VM425619
S9 TOP PAD E9770ED 1VM321492
S10 AC PAD HC461BD 0VM413331
ACCESSORIES
X1 REMOTE CONTROL UNIT NB617ED NB617ED
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY ES-GR6M-C or XB0M571GLP01
DRY BATTERY R6UW/2S XB0M311MS001
X3 RF CORD PAL 1.2M or WPZ0122LG001
RF CABLE CC1001020012010 WPZ0122LW001
X4 ACCESSORY BAG E5700UD 0VM415576
X9 REMOCON BAG E9704ED 1VM422101
X20! OWNERS MANUAL E9G01BD 1VMN23727
X22 QUICK GUIDE E9G01BD 1VMN23728
X31 HANDBILL E8G01BD 1VMN23556
X43 POST CARD E8G00ED 1VMN23493
Ref. No. Description Part No.
