ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
! have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DVD MECHANISM & DVD MAIN CBA
ASSEMBLY
MCV CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
1B2 DVD MECHANISM & DVD MAIN CBA
ASSEMBLY
N78GBDBN
Ref. No. Description Part No.
MCV CBA
Consists of the following
1VSA16004
MAIN CBA (MCV-A )
POWER SW CBA (MCV-B)
FUNCTION CBA (MCV-C)
FRONT JACK CBA (MCV-D)
SENSOR CBA
----------
----------
----------
----------
1VSA11699
Ref. No. Description Part No.
MAIN CBA (MCV-A )
Consists of the following:
----------
CAPACITORS
C251 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
CAP ELECTROLYTIC 10µF/16V/M/H7 CA1C100ENE10
C252 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C253 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C254 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
CAP ELECTROLYTIC 1µF/50V/M/H7 CA1J1R0ENE10
C301 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V CHD1JK30B223
C302 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
CAP ELECTROLYTIC 1µF/50V/M/H7 CA1J1R0ENE10
C303 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C305 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
CAP ELECTROLYTIC 1µF/50V/M/H7 CA1J1R0ENE10
C306 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C307 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V CHD1JK30B223
C308 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C311 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C312 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
CAP ELECTROLYTIC 10µF/16V/M/H7 CA1C100ENE10
C313 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMASSL1R0
CAP ELECTROLYTIC 1µF/50V/M/H7 CA1J1R0ENE09
C314 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C315 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C316 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
CAP ELECTROLYTIC 1µF/50V/M/H7 CA1J1R0ENE10
C317 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C322 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C324 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C325 CHIP CERAMIC CAP. B K 8200pF/50V CHD1JK30B822
C326 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C328 ELECTROLYTIC CAP. 47µF/6.3V M H7 or CE0KMAVSL470
CAP ELECTROLYTIC 47µF/6.3V/M/H7 CA0K470ENE10
C329 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C330 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
CAP ELECTROLYTIC 100µF/16V/M CA1C101ENE12
C331 ELECTROLYTIC CAP. 220µF/6.3V M or CE0KMASDL221
CAP ELECTROLYTIC 220µF/6.3V/M CA0K221ENE12
C333 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C334 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
CAP ELECTROLYTIC 1µF/50V/M/H7 CA1J1R0ENE10
C335 ELECTROLYTIC CAP. 100µF/6.3V H7 or CE0KMAVSL101
CAP ELECTROLYTIC 100µF/6.3V/M/H7 CA0K101ENE10
C336 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C337 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C339 CHIP CERAMIC CAP. CH J 120pF/50V CHD1JJ3CH121
C340 ELECTROLYTIC CAP. 1µF/50V M H7 or CE1JMAVSL1R0
CAP ELECTROLYTIC 1µF/50V/M/H7 CA1J1R0ENE10
C341 CHIP CERAMIC CAP.(1608) CH D 10pF/50V CHD1JD3CH100
C342 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C343 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
CAP ELECTROLYTIC 10µF/16V/M/H7 CA1C100ENE10
C344 ELECTROLYTIC CAP. 4.7µF/25V M NP H7 or CP1EMAVSB4R7
CAP ELECTROLYTIC 4.7µF/25V/M/H7/NP CA1E4R7ENE07
C345 ELECTROLYTIC CAP. 0.47µF/50V M H7 or CE1JMAVSLR47
CAP ELECTROLYTIC 0.47µF/50V/M/H7 CA1JR47ENE10
C347 CHIP CERAMIC CAP.(1608) B K 0.1µF/25V CHD1EK30B104
C349 ELECTROLYTIC CAP. 0.47µF/50V M H7 or CE1JMAVSLR47
CAP ELECTROLYTIC 0.47µF/50V/M/H7 CA1JR47ENE10
C350 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C402 FILM CAP.(P) 0.018µF/50V J or CA1J183MS029
FILM CAP.(P) 0.018µF/100V J CMA2AJP00183
C403 CERAMIC CAP. B K 470pF/100V CCD2AKS0B471
C404 ELECTROLYTIC CAP. 220µF/6.3V M H7 or CE0KMASSL221
CAP ELECTROLYTIC 220µF/6.3V/M/H7 CA0K221ENE09
C405 ELECTROLYTIC CAP. 47µF/6.3V M H7 or CE0KMAVSL470
CAP ELECTROLYTIC 47µF/6.3V/M/H7 CA0K470ENE10
C407 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C408 CHIP CERAMIC CAP. B K 1800pF/50V CHD1JK30B182
C409 CHIP CERAMIC CAP.(1608) CH J 33pF/50V CHD1JJ3CH330
C410 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
CAP ELECTROLYTIC 10µF/16V/M/H7 CA1C100ENE10
C411 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C412 ELECTROLYTIC CAP. 33µF/6.3V M H7 or CE0KMAVSL330
CAP ELECTROLYTIC 33µF/6.3V/M/H7 CA0K330ENE10
C413 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C414 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V CHD1JK30B223
C415 ELECTROLYTIC CAP. 4.7µF/25V M H7 or CE1EMAVSL4R7
CAP ELECTROLYTIC 4.7µF/25V/M/H7 CA1E4R7ENE10
C416 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C417 ELECTROLYTIC CAP. 22µF/6.3V M H7 or CE0KMAVSL220
CAP ELECTROLYTIC 22µF/6.3V/M/H7 CA0K220ENE10
C418 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C419 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C421 ELECTROLYTIC CAP. 47µF/6.3V M H7 or CE0KMAVSL470
CAP ELECTROLYTIC 47µF/6.3V/M/H7 CA0K470ENE10
C451 CHIP CERAMIC CAP.(1608) CH J 22pF/50V CHD1JJ3CH220
C452 ELECTROLYTIC CAP. 10µF/16V M H7 or CE1CMAVSL100
CAP ELECTROLYTIC 10µF/16V/M/H7 CA1C100ENE10
C453 ELECTROLYTIC CAP. 22µF/10V M H7 or CE1AMAVSL220
