20090915 15-118 A91FTEL
JACK CBA(MPW-2)
R675 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R676 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R677 RES CARBON FILM T 1/4W J 1.0k Ω RCX4102T1001
R678 RES CARBON FILM T 1/4W J 10 Ω RCX4100T1001
R679 CHIP RES. 1/10W F 3.6k Ω RRXAFR5H3601
R680 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R682 RES CARBON FILM T 1/4W J 2.7 Ω RCX42R7T1001
R683 RES CARBON FILM T 1/4W J 2.7 Ω RCX42R7T1001
R685 RES CARBON FILM T 1/4W J 22 Ω RCX4220T1001
R687 RES CARBON FILM T 1/4W J 10 Ω RCX4100T1001
R688 RES CARBON FILM T 1/4W J 10 Ω RCX4100T1001
R689 RES CARBON FILM T 1/4W J 1.2k Ω RCX4122T1001
R691 RES CARBON FILM T 1/4W J 2.7 Ω RCX42R7T1001
R692 RES CARBON FILM T 1/4W J 2.7 Ω RCX42R7T1001
R696 METAL RESISTOR 1W J 3.9 Ω RN013R9ZU001
R697 METAL RESISTOR 1W J 3.9 Ω RN013R9ZU001
R723 CHIP RES. 1/10W J 15k Ω RRXAJR5Z0153
R724 CHIP RES. 1/10W J 15k Ω RRXAJR5Z0153
R725 CHIP RES. 1/10W J 39k Ω RRXAJR5Z0393
R726 CHIP RES. 1/10W J 39k Ω RRXAJR5Z0393
R731 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R732 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R733 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R734 CHIP RES. 1/10W J 10 Ω RRXAJR5Z0100
R735 CHIP RES. 1/10W J 10 Ω RRXAJR5Z0100
R736 CHIP RES. 1/10W J 10 Ω RRXAJR5Z0100
R743 CHIP RES. 1/10W J 15k Ω RRXAJR5Z0153
R744 CHIP RES. 1/10W J 15k Ω RRXAJR5Z0153
R745 CHIP RES. 1/10W J 39k Ω RRXAJR5Z0393
R746 CHIP RES. 1/10W J 39k Ω RRXAJR5Z0393
R763 RES CARBON FILM T 1/4W J 10k Ω RCX4103T1001
R771 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
R772 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R773 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R774 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R775 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R776 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R777 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R778 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R779 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R802 CHIP RES. 1/10W F 27k Ω RRXAFR5H2702
R803 CHIP RES. 1/10W F 11k Ω RRXAFR5H1102
R804 CHIP RES. 1/10W F 11k Ω RRXAFR5H1102
R806 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R810 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
R813 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R814 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R815 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R816 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R817 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R818 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R819 RES CARBON FILM T 1/4W J 22k Ω RCX4223T1001
R820 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R843 CHIP RES. 1/10W J 110 Ω RRXAJR5Z0111
R844 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R847 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R848 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R871 CHIP RES. 1/10W J 560 Ω RRXAJR5Z0561
R872 CHIP RES. 1/10W J 560 Ω RRXAJR5Z0561
R873 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R874 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R877 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R878 RES CARBON FILM T 1/4W J 1.0k Ω RCX4102T1001
Ref. No. Description Part No.
R879 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R880 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R881 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R882 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R883 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R884 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R885 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R886 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R887 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R888 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R891 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R892 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R893 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R894 RES CARBON FILM T 1/4W J 1.0k Ω RCX4102T1001
MISCELLANEOUS
AC601# AC CORD UL 1855MM BLACK WAC0182LW007
B11 POW HEAT SINK A7120UH 1EM423993
B12 MODULE HEAT SINK PMC P7150UT 1EM423968
BC301 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
BC601 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC801 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC802 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC803 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC804 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC805 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC841 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
CL602 WIRE ASSEMBLY 2PIN 2PIN 90MM RED
BLACK
WX1A91FS-204
CL701 WIRE ASSEMBLY 9P 9PIN/170MM WX1A94F0-002
F601# FUSE STC4A125V U/CT PAGE20CW3402
FH601 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
FH602 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
JK721 JACK RCA PCB S WHITE 01/RCA-101H(WH) JXRJ010YUQ02
JK722 JACK RCA PCB S RED 01/RCA-101H(RD) JXRJ010YUQ01
JK731 JACK RCA PCB S GREEN 01/RCA-101H(GN) JXRJ010YUQ03
JK732 JACK RCA PCB S BLUE 01/RCA-101H(BL) JXRJ010YUQ04
JK733 JACK RCA PCB S RED 01/RCA-101H(RD) JXRJ010YUQ01
JK741 JACK RCA PCB S WHITE 01/RCA-101H(WH) JXRJ010YUQ02
JK742 JACK SW RCA PCB S RED RCA-102H(RD) JYRJ010YUQ03
JK841 JACK RCA PCB S ORANGE 01/RCA-101H(OR) JXRJ010YUQ06
JK871 JACK RCA PCB S WHITE 01/RCA-101H(WH) JXRJ010YUQ02
JK872 JACK RCA PCB S RED 01/RCA-101H(RD) JXRJ010YUQ01
JS102 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
JS302 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
JS303 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
JS304 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
L3 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
SA601# SURGE ABSORBER 470V+-10PER NVQZ10D471KB
T601# TRANS POWER BCK-28-9910A LTT2PC0XB057
TM601 EYELET TYPE D-1 0VM406868
TM602 EYELET TYPE D-1 0VM406868
TU301 TUNER UNIT ATSC/NTSC/QAM TDAU4-D02A UTUNNTUAL052
Ref. No. Description Part No.
JACK CBA(MPW-2)
Consists of the following:
----------
CAPACITORS
C754 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
C755 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
C756 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
C757 CHIP CERAMIC CAP.(1608) B K 2.2µF/10V CHD1AK30B225
Ref. No. Description Part No.
