INVERTER ASSEMBLY
INVERTER POWER CBA
C758 CHIP CERAMIC CAP.(1608) B K 2.2µF/10V CHD1AK30B225
RESISTORS
R751 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R752 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R753 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R756 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R757 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R758 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R759 CHIP RES. 1/10W J 15k Ω RRXAJR5Z0153
R760 CHIP RES. 1/10W J 15k Ω RRXAJR5Z0153
R761 CHIP RES. 1/10W J 39k Ω RRXAJR5Z0393
R762 CHIP RES. 1/10W J 39k Ω RRXAJR5Z0393
MISCELLANEOUS
JK751 JACK SW DIN PCB L DIN-435C(777D) JYEL040YUQ03
JK752 JACK RCA PCB L RCA-101S(1)-03 JXRL010YUQ12
JK753 JACK RCA PCB L RCA-101S(1)-04 JXRL010YUQ13
JK754 JACK SW RCA PCB L RCA-102F(RD) JYRL010YUQ05
Ref. No. Description Part No.
INVERTER ASSEMBLY
Consists of the following:
A91FSM1V-001
INVERTER POWER CBA
---------------------------------------------------------------------
FUNCTION CBA
IR SENSOR CBA
JUNCTION CBA
A91FSM1V-001-IV
----------------------------
A91FSM1V-001-FNIRJN
Ref. No. Description Part No.
INVERTER POWER CBA
Consists of the following:
----------
CAPACITORS
C1620 POLYESTER FILM CAP. (PB FREE) 0.001µF/
100V J
CA2A102DT018
C1650 ELECTROLYTIC CAP. 22µF/50V M CE1JMASDL220
C1651 POLYESTER FILM CAP. (PB FREE) 0.022µF/
100V J
CA2A223DT018
C1652 CAP CERAMIC (AX) 0.01µF/50V/B/K CA1J103TU061
C1653 CAP CERAMIC (AX) 0.01µF/50V/B/K CA1J103TU061
C1801 ELECTROLYTIC CAP. 22µF/50V M CE1JMASDL220
C1802 POLYESTER FILM CAP. (PB FREE) 0.022µF/
100V J
CA2A223DT018
C1803 POLYESTER FILM CAP. (PB FREE) 0.01µF/
100V J
CA2A103DT018
C1905# SAFTY CAP. 2200pF/250V KX CA2E222MR101
C1910 CAP ELECTROLYTIC 270µF/200V CEA271DYG005
C1930 CERAMIC CAP. 820pF/2KV CA3D821PAN04
C1931# POLYESTER FILM CAP. (PB FREE) 0.001µF/
100V J
CA2A102DT018
C1932 POLYESTER FILM CAP. (PB FREE) 0.056µF/
100V J
CA2A563DT018
C1933 POLYESTER FILM CAP. (PB FREE) 0.1µF/100V
J
CA2A104DT018
C1941 CERAMIC CAP. B K 0.01µF/1KV CCD3AKN0B103
C1970 POLYESTER FILM CAP. (PB FREE) 0.0022µF/
100V J
CA2A222DT018
C1981 POLYESTER FILM CAP. (PB FREE) 0.01µF/
100V J
CA2A103DT018
C1982 ELECTROLYTIC CAP. 0.47µF/50V M CE1JMASDLR47
C1990 CERAMIC CAP. 3300pF/1KV CCD3AKA0R332
C1992 ELECTROLYTIC CAP. 2200µF/35V M CE1GMZNDL222
C1995 ELECTROLYTIC CAP. 2200µF/35V M CE1GMZNDL222
CONNECTORS
Ref. No. Description Part No.
CN1001 FPC/FFC CONNECTOR IMSA-9615S-05A-PP-
A
JC96J05ER007
CN1900# CONNECTOR B2P3-VH(LF)(SN) J3VH020JG001
DIODES
D1651 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1930# DIODE ZENER 27BSB-T26 NDTB027BST26
D1931 DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
D1932 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1933 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1934# DIODE ZENER 39BSB-T26 NDTB039BST26
D1940 DIODE FAST RECOVERY FR155-B/P NDWZ0FR155BP
D1960 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
D1970 DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
D1971 DIODE ZENER HZS33NB2TE-EQ QDTBHZS33NB2
D1990 DIODE SCHOTTKY YG862C15R QDWZYG862C15
D1994# DIODE ZENER 1ZB30BB NDWZ0001ZB30
ICS
IC1930# PHOTO COUPLER LTV817MCF NPECLTV817MF
IC1931# PHOTO COUPLER LTV817MCF NPECLTV817MF
COILS
L1601 INDUCTOR 100µH-J-26T LLAXJATTU101
L1602 INDUCTOR 100µH-J-26T LLAXJATTU101
TRANSISTORS
Q1650 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1651 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1652 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q1800 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1930# FET MOS 2SK3561(Q) IDSS100UA QFWZ2SK3561Q
Q1931# TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1932# TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q1970 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1971 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
Q1972 TRANSISTOR KTC3198-Y-AT/P NQSYKTC3198P
RESISTORS
R1650 RES CARBON FILM T 1/4W J 100 Ω RCX4101T1001
R1651 RES CARBON FILM T 1/4W J 10k Ω RCX4103T1001
R1652 RES CARBON FILM T 1/4W J 22k Ω RCX4223T1001
R1653 RES CARBON FILM T 1/4W J 3.3k Ω RCX4332T1001
R1654 RES CARBON FILM T 1/4W J 10k Ω RCX4103T1001
R1655 RES CARBON FILM T 1/4W J 6.8k Ω RCX4682T1001
R1656 RES CARBON FILM T 1/4W J 47k Ω RCX4473T1001
R1657 RES CARBON FILM T 1/4W J 100k Ω RCX4104T1001
R1658 RES CARBON FILM T 1/4W J 220k Ω RCX4224T1001
R1800 RES CARBON FILM T 1/4W J 10k Ω RCX4103T1001
R1801 RES CARBON FILM T 1/4W J 47k Ω RCX4473T1001
R1803 RES CARBON FILM T 1/4W J 10k Ω RCX4103T1001
R1930 RES CARBON FILM T 1/4W J 47 Ω RCX4470T1001
R1931 RES CARBON FILM T 1/4W J 47k Ω RCX4473T1001
R1932 RES CARBON FILM T 1/4W J 120 Ω RCX4121T1001
R1933 RES CARBON FILM T 1/4W J 120 Ω RCX4121T1001
R1934 RES CARBON FILM T 1/4W J 120 Ω RCX4121T1001
R1935 RES CARBON FILM T 1/4W J 1.2k Ω RCX4122T1001
R1936 RES CARBON FILM T 1/4W J 180 Ω RCX4181T1001
R1937# METAL OXIDE FILM RES. 2W J 0.47 Ω RN02R47ZU001
R1938 METAL RESISTER. 2W J 0.56 Ω RN02R56ZU001
R1939 RES CARBON FILM T 1/4W J 2.2k Ω RCX4222T1001
R1940 RES CARBON FILM T 1/4W J 220k Ω RCX4224T1001
R1941 RES CARBON FILM T 1/4W J 220k Ω RCX4224T1001
R1942 RES CARBON FILM T 1/4W J 270k Ω RCX4274T1001
R1943 RES CARBON FILM 1/4W J 820k Ω RCX4824FS002
R1944 RES CARBON FILM 1/4W J 820k Ω RCX4824FS002
R1945 RES CARBON FILM T 1/4W J 390k Ω RCX4394T1001
Ref. No. Description Part No.
To Next Page
