FUNAI LC320SLX - Page 240

20090915 15-120 A91FTEL
FUNCTION CBA
IR SENSOR CBA
JUNCTION CBA
R1946 METAL OXIDE RES. 1W J 47k Ω RN01473ZU001
R1947 METAL OXIDE RES. 1W J 47k Ω RN01473ZU001
R1969 RES CARBON FILM T 1/4W J 3.3k Ω RCX4332T1001
R1970 RES CARBON FILM T 1/4W J 120 Ω RCX4121T1001
R1975 RES CARBON FILM T 1/4W G 20k Ω RCX4203T1002
R1979 RES CARBON FILM T 1/4W G 6.8k Ω RCX4682T1002
R1980 RES CARBON FILM T 1/4W G 270 Ω RCX4271T1002
R1981 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
R1982 RES CARBON FILM T 1/4W J 2.2k Ω RCX4222T1001
R1986 RES CARBON FILM T 1/4W J 1.0k Ω RCX4102T1001
R1987 RES CARBON FILM 1/4W J 820k Ω RCX4824FS002
R1988 RES CARBON FILM T 1/4W J 1.0k Ω RCX4102T1001
MISCELLANEOUS
B33 HEAT SINK PND ASSEMBLY A91F2UH 1EM428182
BC1930 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC1931 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
CL1003 WIRE ASSEMBLY 13P 13PIN/120MM WX1A91FS-201
JS1001 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
JS1002 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
L3 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
T1950# TRANS INVPOW BCK-28-9909D LTT2PC0XB056
Ref. No. Description Part No.
FUNCTION CBA
Consists of the following:
----------
CAPACITOR
C108 CAP CERAMIC (AX) 0.1µF/50V/F/Z CA1J104TU062
RESISTORS
R108 RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R109 RES CARBON FILM T 1/4W G 10k Ω RCX4103T1002
R111 RES CARBON FILM T 1/4W G 4.7k Ω RCX4472T1002
R112 RES CARBON FILM T 1/4W G 2.7k Ω RCX4272T1002
R113 RES CARBON FILM T 1/4W G 4.7k Ω RCX4472T1002
R114 RES CARBON FILM T 1/4W G 8.2k Ω RCX4822T1002
R115 RES CARBON FILM T 1/4W G 18k Ω RCX4183T1002
SWITCHES
SW101A TACT SWITCH SKHHLMA010 SST0101AL049
SW103A TACT SWITCH SKHHLMA010 SST0101AL049
SW104A TACT SWITCH SKHHLMA010 SST0101AL049
SW105A TACT SWITCH SKHHLMA010 SST0101AL049
SW106A TACT SWITCH SKHHLMA010 SST0101AL049
SW107A TACT SWITCH SKHHLMA010 SST0101AL049
Ref. No. Description Part No.
IR SENSOR CBA
Consists of the following:
----------
CAPACITORS
C113 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C115 CAP CERAMIC (AX) 330pF/50V/B/K CA1J331TU061
DIODES
D104 LED GREEN 333GT/E(FNA) NPWZ33GTEFNA
D105 LED L-53HT NP4Z000L53HT
RESISTORS
R123 RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R124 RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R126 RES CARBON FILM T 1/4W J 1.0k Ω RCX4102T1001
R127 RES CARBON FILM T 1/4W J 3.3k Ω RCX4332T1001
R128 RES CARBON FILM T 1/4W J 100 Ω RCX4101T1001
MISCELLANEOUS
Ref. No. Description Part No.
CL102 WIRE ASSEMBLY 8P 8PIN/240MM WX1A91FS-001
CL103 WIRE ASSEMBLY 4P 4PIN/250MM WX1A94F0-003
RS102 SENSOR REMOTE RECEIVER KSM-712TH2E USESJRSKK044
Ref. No. Description Part No.
JUNCTION CBA
Consists of the following:
----------
CONNECTOR
CN101 242 SERIES CONNECTOR TUC-P08X-B1 WHT
ST
JCTUB08TG002
Ref. No. Description Part No.
